26-20-2131

厂商：
MOLEX3
封装：
描述：
26-20-2131 - 3.96mm (.156") Pitch KK Wire-to-Board Header, Vertical Round Pin, 13 Circuits, Tin (Sn)...

数据手册：

下载26-20-2131.pdf

立即购买

详情介绍
数据手册
价格&库存

26-20-2131 数据手册

This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0026202131 Active kk 3.96mm (.156") Pitch KK® Wire-to-Board Header, Vertical Round Pin, 13 Circuits, Tin (Sn) Plating, with Mating Pin Length of 11.43mm (.450") Documents: 3D Model Drawing (PDF) Product Specification PS-99020-0087 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification UL General Product Family Series Application Overview Product Name PCB Headers 3192 Board-to-Board, Wire-to-Board kk KK® Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) First Mate / Last Break Flammability Glow-Wire Compliant Guide to Mating Part Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Shrouded Stackable Temperature Range - Operating No 13 13 Natural 25 No 94V-2 No No None None Brass Tin Tin Nylon 1 Vertical 0.175 In 4.45 mm No None 0.062 In 1.60 mm Bag 0.156 In 3.96 mm 200 5 200 5 No No No Yes 0°C to +75°C Search Parts in this Series 3192Series Mates With 3069 KK® Crimp Terminal Housing. 3215 KK® PC Board Connector Termination Interface: Style Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 7A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 319213A Reference - Drawing Numbers Product Specification Sales Drawing PS-99020-0087 SDAE-3192-N* This document was generated on 05/26/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

26-20-2131

物料型号： - 型号：0026202131 - 状态：Active（活跃）

器件简介： - 描述：3.96mm（.156"）间距KK®线对板连接器，垂直圆形针，13路，锡（Sn）镀层，配对针长度为11.43mm（.450"）。

引脚分配： - 电路（最大）：13路

参数特性： - 颜色 - 树脂：自然色 - 耐用性（最大插拔次数）：25次 - 阻燃等级：94V-2 - 金属材质：黄铜 - 镀层材质：锡 - 树脂材质：Nylon - 行数：未提供 - 方向：垂直 - PCB尾长：0.175英寸（4.45mm） - 推荐PCB厚度：0.062英寸（1.60mm） - 包装类型：袋装 - 配合界面间距：0.156英寸（3.96mm） - 镀层最小厚度：Mating（200微英寸/5微米），Termination（200微英寸/5微米） - 操作温度范围：0°C至+75°C

功能详解： - 产品系列：3192 - 应用：板对板、线对板 - 产品名称：KKR - 可堆叠：是

应用信息： - 与3069 KK®压接端子外壳和3215 KK®PCB连接器配合使用。

封装信息： - 封装类型：通孔 - 电气：每接触最大电流7A，最大电压250V - 无铅焊接工艺能力：波峰焊（TH only）
