38-00-2399

This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0038002399 Active kk 2.54mm (.100") Pitch KK® Connector, IDT, High Pressure Cat Ear Contact System, Green ID Stripe, 9 Circuit Documents: Drawing (PDF) Product Specification PS-99020-0088 (PDF) Product Specification PSX-7690S (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification UL General Product Family Series Comments Crimp Quality Equipment Overview Product Name IDT and Solder Connectors 7690 Version H Yes kk KK® Physical Circuits (Loaded) Color - Resin Durability (mating cycles max) Flammability Gender Glow-Wire Compliant Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Temperature Range - Operating Wire Size AWG 9 Natural 25 94V-2 Female No Yes Brass Tin Tin Nylon 1 Bag No 0.100 In 2.54 mm 40 1.00 40 1.00 0°C to +75°C 24 Stranded, 26 Solid, 26 Stranded Topcoat Search Parts in this Series 7690Series Mates With Molex KK® 2.54mm (.100") pitch headers and 0.64mm (.025") pins Electrical Current - Maximum per Contact Voltage - Maximum 2.5A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Old Part Number 7690SC09H Reference - Drawing Numbers Product Specification PS-99020-0088, PSX-7690S Sales Drawing SDA-7690S-*N* This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
