39-00-0123

This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0039000123 Active minifit_jr 4.20mm (.165") Pitch Mini-Fit™ Crimp Terminal, Male, Tin (Sn), Brass, 22-28 AWG, Bag Documents: Test Summary (PDF) Drawing (PDF) Product Specification PS-5556-001 (PDF) Product Specification PS-5556-002 (PDF) Product Specification PS-5556-003 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 5558 Yes minifit_jr Mini-Fit® Physical Durability (mating cycles max) Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² 30 Male Brass Tin Tin Bag 100 2.5 100 2.5 Crimp or Compression 0.90-1.80mm (.035-.071") 22, 24, 26, 28 N/A Search Parts in this Series 5558Series Mates With 5556 Mini-Fit™ Crimp Terminal Use With 5559 Mini-Fit Jr.™ Plug Housing, 30068 Mini-Fit TPA™ Plug Housing, 42475 Mini-Fit BMI™ Plug Housing Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool for 0638191000 Mini-Fit Jr.™ Crimp Termianls Electrical Current - Maximum per Contact Voltage - Maximum 9A 600V Material Info Old Part Number 5558-S2L Reference - Drawing Numbers Packaging Specification Product Specification Test Summary PK-5556-003 PS-5556-001, PS-5556-002, PS-5556-003 TS-5556-002 This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
