39-00-0337

This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0039000337 Active standard_062 1.57mm (.062") Diameter, Standard .062" Pin and Socket Crimp Terminal, Series 1854, 3.68mm (.145") Pitch, Male, Gold (Au) Plated Brass Contact, 22-28 AWG, Bag Documents: Drawing (PDF) Product Specification PS-1854-001 (PDF) RoHS Certificate of Compliance (PDF) Series General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 1854 Yes standard_062 Standard .062" image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Durability (mating cycles max) Gender Material - Metal Material - Plating Mating Material - Plating Termination Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² 30 Male Brass Gold Gold Bag 14 0.35 14 0.35 Crimp or Compression 1.10-1.50mm (.043-.059") 22, 24, 26, 28 0.08-0.32 Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Search Parts in this Series 1854Series Mates With 1855 Crimp Terminal Use With 1625np Plug Housing Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0638190800 Manual Extraction 0011030002 Tool Japan Description Product # Hand Crimp Tool 0011260009 JHTR2262A Material Info Old Part Number 1854GL Reference - Drawing Numbers Product Specification Sales Drawing PS-1854-001 SD-1854* Hand Insertion Tool 0011020001 Hand Extraction Tool 0011267034 This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
