Part Number: Status: Overview: Description:
0050579503 Active
cgrid__sl_products 2.54mm (.100") Pitch SL™ Crimp Housing, Single Row, Version H, Polarized Friction Lock, 3 Circuits
Documents: 3D Model Drawing (PDF) Packaging Specification (PDF)
Product Specification PS-70058 (PDF) Product Specification PS-70400 (PDF) RoHS Certificate of Compliance (PDF) image - Reference only
Series
Agency Certification
CSA TUV UL LR19980 R72081037 E29179 EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions.
General
Product Family Series Comments Overview Product Name Crimp Housings 70066 Version H cgrid__sl_products SL™
Physical
Circuits (maximum) Color - Resin Flammability Gender Glow-Wire Compliant Material - Resin Number of Rows Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Stackable Temperature Range - Operating 3 Black 94V-0 Female No Polyester Alloy 1 Bag No 0.100 In 2.54 mm Yes -40°C to +105°C
Search Parts in this Series 70066Series Mates With 6373 Straight Header, 7478 Use With 70058 , 71851
Material Info
Old Part Number 700660212
Reference - Drawing Numbers
Packaging Specification Product Specification Sales Drawing Test Summary PK-70066-100 PS-70058, PS-70400 SD-70066-0211-0234 TS-70058-001
