97-00-0450

This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0097000450 Active kk KK® Cat Ear Crimp Terminal 4809, 22-30 AWG, Un-plated, Reel Documents: 3D Model Drawing (PDF) Product Specification PS-10-07 (PDF) Product Specification PS-99020-0088 (PDF) RoHS Certificate of Compliance (PDF) Series General Product Family Series Crimp Quality Equipment Overview Product Name Crimp Terminals 4809 Yes kk Cat Ear, KK® image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Halogen-Free Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. PS-10-07, PS-99020-0088 SD-4809C-(***)* Search Parts in this Series 4809Series Use With 5051, 6471 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Extraction Tool 0011030022 Terminator Die 0011402102 Insertion Tool 0638120000 Mini-Mac™ for KK® 0638887000 Cat Ear and Anti Fish Hook Crimp Terminals, 22-30 AWG Physical Gender Material - Metal Material - Plating Mating Packaging Type Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Female Brass Unplated Reel Crimp or Compression 1.57mm (.062") max. 22, 24, 26, 28, 30 N/A Material Info Reference - Drawing Numbers Product Specification Sales Drawing This document was generated on 06/01/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
