AA-822-14T

This document was generated on 05/10/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0190730026 Active Avikrimp™ Ring Tongue Terminal for 18 to 22 AWG Wire, Stud Size 1/4", Length 26.90mm (1.059"), Mylar Tape Carrier Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19073 Yes N/A Avikrimp™ Ring Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-0 Nylon (PA) Tin Adhesive Tape on Reel 1/4" (M6) 3.60mm (.142") max. 18, 20, 22 0.35 - 0.80 Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Material Info Old Part Number AA-822-14T Search Parts in this Series 19073Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Crimp Dies for 0192880023 MTA-100 Tape Applicator used in 3BF Press, MTA-105 Tape Applicator used in TM-2000™ Press, and ATP-301 Air Crimping Press for Mylar Tape Mounted Terminals Mini-Mac™ 0638851300 Applicator Reference - Drawing Numbers Sales Drawing SD-19073-003 This document was generated on 05/10/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
