AA-822-56

This document was generated on 04/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0190730027 Active Avikrimp™ Ring Tongue Terminal for 18 to 22 AWG Wire, Stud Size 5/16", Length 26.90mm (1.059") Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series General Product Family Series Comments Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19073 Type II Insulated; Class 1 and 2 Yes AS25036-104, MS25036-104 Avikrimp™ Ring Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Stud Size Termination Interface: Style Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-0 Nylon (PA) Tin Bag 100 2.5 100 2.5 5/16" (M8) Crimp or Compression 3.60mm (.142") max. 18, 20, 22 0.35 - 0.80 Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Search Parts in this Series 19073Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0640010100 Hand Crimp Tool 0640011200 Crimp Head for the 0640050100 AT-200™ Pneumatic Hand Tool Crimp Head for the 0640051200 AT-200™ Pneumatic Hand Tool Material Info Old Part Number AA-822-56 Reference - Drawing Numbers Sales Drawing SD-19073-003 This document was generated on 04/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
