BB-223-02XT

This document was generated on 03/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0190700066 Active RING INSULKRIMP TAPED (BB-223-02XT) Documents: Drawing (PDF) Product Specification PS-19902-009 (PDF) RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19070 Yes N/A InsulKrimp™ Ring Physical Barrel Type Color - Resin Flammability Insulation Material - Plating Mating Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed Natural 94V-2 PVC Tin Adhesive Tape on Reel 160 4 160 4 1-2 (M2) 4.40mm (.175") max. 14, 16 1.30 - 2.00 Search Parts in this Series 19070Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Crimp Dies for 0192880123 MTA-100 Tape Applicator used in 3BF Press, MTA-105 Tape Applicator used in TM-2000™ Press, and ATP-301 Air Crimping Press for Mylar Tape Mounted Terminals Mini-Mac™ 0638850400 Applicator Material Info Old Part Number BB-223-02XT Reference - Drawing Numbers Product Specification Sales Drawing PS-19902-009 SD-19070-004 This document was generated on 03/18/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
