SC-12-10

This document was generated on 06/04/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0191640056 Active Perma-Seal™ Butt Splice for 10-12 AWG Wire Agency Certification CSA UL LR18689 E32244 General Product Family Series Crimp Quality Equipment Mil-Spec MolexKits Product Name Splices 19164 Yes N/A Yes Butt, Perma-Seal™ EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Physical Barrel Type Flammability Insulation Packaging Type Temperature Range - Operating Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-0 NiAc™ Bag -55°C to +125°C 7.87mm (.310") max 10, 12 3.09 - 5.01 Search Parts in this Series 19164Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Power Crimp Tool 0640057400 Head for PremaSeal™ Terminals 10-22 AWG Hand Crimp Tool, UL 0640017400 Approved Electrical Voltage - Maximum 600V Material Info Old Part Number SC-12-10 Reference - Drawing Numbers Sales Drawing SD-19164-017 This document was generated on 06/04/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
