SC-12-10T

This document was generated on 03/16/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: Documents: Drawing (PDF) 0191640057 Active Perma-Seal™ Butt Splice for 10-12 AWG Wire, Mylar Tape Carrier RoHS Certificate of Compliance (PDF) Series LR18689 E32244 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Splices 19164 Yes N/A Butt - Funnel Entry, Perma-Seal™ Physical Barrel Type Flammability Insulation Packaging Type Temperature Range - Operating Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-0 NiAc™ Adhesive Tape on Reel -55°C to +125°C 7.8mm (.31") max 10, 12 3.09 - 5.01 Electrical Voltage - Maximum 600V Material Info Old Part Number SC-12-10T Search Parts in this Series 19164Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Crimp Dies for 0192880279 MTA-100 Tape Applicator used in 3BF Press, MTA-105 Tape Applicator used in TM-2000™ Press, and ATP-301 Air Crimping Press for Mylar Tape Mounted Terminals Hand Crimp Tool, UL 0640017400 Approved Power Crimp Tool 0640057400 Head for Prema- Reference - Drawing Numbers Sales Drawing SD-19164-017 Seal™ Terminals 10-22 AWG This document was generated on 03/16/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
