SC-228-08

This document was generated on 04/14/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: Documents: Drawing (PDF) 0191640062 Active Perma-Seal™ Ring Tongue Terminal for 10-12 AWG Wire, Stud Size 8 RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19164 Yes N/A Perma-Seal™ Ring Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-2 NiAc™ Tin Bag 8 (M4) 7.87mm (.310") 10, 12 3.09 - 5.01 Material Info Old Part Number SC-228-08 Search Parts in this Series 19164Series SD-19164-041 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Power Crimp Tool 0640057400 Head for PremaSeal™ Terminals 10-22 AWG Hand Crimp Tool, UL 0640017400 Approved Reference - Drawing Numbers Sales Drawing This document was generated on 04/14/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
