This document was generated on 03/16/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: 0191640316 Active Perma-Seal™ Ring Tongue Terminal for 10-12 AWG Wire, Stud Size 10, Mylar Tape Carrier Documents: Drawing (PDF) RoHS Certificate of Compliance (PDF) Agency Certification UL E32244 image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Series General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19164 Yes N/A Perma-Seal™ Ring Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-2 NiAc™ Tin Adhesive Tape on Reel 100 2.5 100 2.5 10 (M5) 7.87mm (.310") 14, 16 1.23 - 1.94 Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Search Parts in this Series 19164Series Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # ATP Perishable Tool 0198082025 Kit Used in ATP Presses that Process Product on Tape Hand Crimp Tool, UL 0640017400 Approved Power Crimp Tool 0640057400 Head for PremaSeal™ Terminals 10-22 AWG Material Info Old Part Number SC-230-10T Reference - Drawing Numbers Sales Drawing SD-19164-041 This document was generated on 03/16/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
