SD-651-56

This document was generated on 04/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Description: Documents: Drawing (PDF) 0191640083 Active Perma-Seal™ Ring Tongue Terminal for 8 AWG Wire, Stud Size 5/16 RoHS Certificate of Compliance (PDF) Agency Certification CSA UL LR18689 E32244 Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Contains SVHC: No Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Crimp Quality Equipment Mil-Spec Product Name Type Ring and Spade Terminals 19164 Yes N/A Perma-Seal™ Ring Physical Barrel Type Flammability Insulation Material - Plating Mating Packaging Type Stud Size Wire Insulation Diameter Wire Size AWG Wire Size mm² Closed 94V-0 NiAc™ Tin Bag 5/16" (M8) 9.53mm (.375") 8 7.96 Material Info Old Part Number SD-651-56 Search Parts in this Series 19164Series SD-19164-023 Application Tooling | FAQ Tooling specifications and manuals are found by selecting the products below. Crimp Height Specifications are then contained in the Application Tooling Specification document. Global Description Product # Hand Crimp Tool 0640013900 Crimp Head for the 0640050100 AT-200™ Pneumatic Hand Tool Crimp Head for the 0640055400 AT-200™ Pneumatic Hand Tool Reference - Drawing Numbers Sales Drawing This document was generated on 04/12/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
