47589-0001

This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0475890001 Active micro_usb 0.65mm (.026") Pitch Micro-USB AB Receptacle, Right Angle, Bottom Mount, SMT, Lead Free Documents: 3D Model Drawing (PDF) Product Specification PS-47589-001 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only I/O Connectors 47589 Wire-to-Board Bottom Mount Type Receptacle micro_usb Micro-USB AB EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. General Product Family Series Application Comments Component Type Overview Product Name Type Physical Boot Color Circuits (Loaded) Circuits (maximum) Color - Resin Gender Keying to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PCB Locator PCB Retention Packaging Type Panel Mount Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Pitch - Term. Interface (in) Pitch - Term. Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Polarized to PCB Ports Surface Mount Compatible (SMC) Temperature Range - Operating Termination Interface: Style Waterproof / Dustproof N/A 5 5 Black Male Yes Yes Copper Alloy Gold Gold High Temperature Thermoplastic 1 Right Angle Yes Yes Embossed Tape on Reel No 0.026 In 0.65 mm 0.026 In 0.65 mm 43 0.11 2 0.05 Yes Yes 1 Yes -20°C to +85°C Surface Mount No Search Parts in this Series 47589Series Mates With 47516 Micro-USB Plug Electrical Current - Maximum per Contact 1.8A, 1A Grounding to Panel Shield Type Shielded Voltage - Maximum Yes Full Shield Yes 100V AC (RMS) Material Info Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-47589-001 PS-47589-001 SD-47589-001 This document was generated on 05/19/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
