705-63-0057

This document was generated on 05/28/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0705630057 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ Header, Single Row, Vertical, .180" Pocket, Shrouded, 23 Circuits, Tin (Sn) Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-70400 (PDF) Product Specification PS-70541 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL LR19980 E29179 General Product Family Series Application Overview Product Name PCB Headers 70563 Wire-to-Board cgrid__sl_products SL™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Lock to Mating Part Material - Plating Mating Material - Plating Termination Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Shrouded Stackable Temperature Range - Operating Termination Interface: Style No 23 23 25 94V-0 No Yes Yes Tin Tin 1 Vertical 0.130 In 3.30 mm No None 0.062 In 1.60 mm Tube 0.100 In 2.54 mm 150 3.80 150 3.80 Yes Fully No -40°C to +105°C Through Hole Search Parts in this Series 70563Series Mates With 70004 Electrical Current - Maximum per Contact 3A Voltage - Maximum 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0016 PS-70400, PS-70541 SDA-70563-**** This document was generated on 05/28/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
