705-63-0115

厂商：
MOLEX8
封装：
描述：
705-63-0115 - 2.54mm (.100") Pitch SL™ Header, Single Row, Vertical, .180" Pocket, Shrouded, 11 Circ...

数据手册：

下载705-63-0115.pdf

立即购买

详情介绍
数据手册
价格&库存

705-63-0115 数据手册

This document was generated on 05/28/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0705630115 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ Header, Single Row, Vertical, .180" Pocket, Shrouded, 11 Circuits, 0.76µm (30µ") Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-70400 (PDF) Product Specification PS-70541 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL LR19980 E29179 General Product Family Series Application Overview Product Name PCB Headers 70563 Wire-to-Board cgrid__sl_products SL™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Shrouded Stackable Temperature Range - Operating Termination Interface: Style No 11 11 Black 50 94V-0 No Yes Yes Brass, Phosphor Bronze Gold Tin High Temperature Thermoplastic 1 Vertical 0.130 In 3.30 mm No None 0.062 In 1.60 mm Tube 0.100 In 2.54 mm 30 0.75 75 1.875 Yes Fully No -40°C to +105°C Through Hole Search Parts in this Series 70563Series Mates With 70004 Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0016 PS-70400, PS-70541 SDA-70563-**** This document was generated on 05/28/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

705-63-0115

1. 物料型号： - 型号：0705630115 - 状态：Active（活跃） - 符合欧盟RoHS、中国RoHS、ELV和RoHS标准，REACH SVHC未审核，卤素含量状态未审核。

2. 器件简介： - 产品名称：SLTM Header - 描述：2.54mm（.100"）Pitch SLTM Header，单排，垂直，.180" Poc Circuits，0.76um（30u"）金（Au）选择性镀层，锡（Sn）PC Ta。

3. 引脚分配： - 电路（已加载）：11 - 最大电路数：11

4. 参数特性： - 颜色 - 树脂：黑色 - 耐久性（最大插拔次数）：50次 - 阻燃等级：94V-0 - 热丝合规性：否 - 导向到配对部件：是 - 材料 - 金属：黄铜，锡磷青铜 - 材料 - 镀层配对：金 - 材料 - 镀层终止：锡 - 材料 - 树脂：高温热塑性塑料 - 取向：垂直 - PCB尾长（英寸）：0.130 In - PCB尾长（毫米）：3.30 mm - PCB定位器：无 - PCB保持：无 - 推荐PCB厚度（英寸）：0.062 In - 推荐PCB厚度（毫米）：1.60 mm - 包装类型：管装 - 配对接口间距（英寸）：0.100 In - 配对接口间距（毫米）：2.54 mm - 镀层最小：配对（uin）：30 - 镀层最小：配对（um）：0.75 - 镀层最小：终止（uin）：75 - 镀层最小：终止（um）：1.875

5. 功能详解： - 系列：PCB Headers - 应用：线对板 - 产品系列：70563 - 配对部件：Mates With 70004

6. 应用信息： - 应用：线对板

7. 封装信息： - 完全封闭：是 - 可堆叠：否 - 工作温度范围：-40°C至+105°C - 终止接口：通孔
