705-75-0041

厂商：
MOLEX8
封装：
描述：
705-75-0041 - 2.54mm (.100) Pitch SL™ Header, Single Row, Right Angle, .180" Pocket, Shrouded, with ...

数据手册：

下载705-75-0041.pdf

立即购买

详情介绍
数据手册
价格&库存

705-75-0041 数据手册

This document was generated on 05/31/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION Part Number: Status: Overview: Description: 0705750041 Active cgrid__sl_products 2.54mm (.100") Pitch SL™ Header, Single Row, Right Angle, .180" Pocket, Shrouded, with Press-fit Plastic Peg, 7 Circuits, 0.38µm (15µ") Gold (Au) Selective Plating, Tin (Sn) PC Tail Plating Documents: 3D Model Drawing (PDF) Packaging Specification (PDF) Product Specification PS-70400 (PDF) Product Specification PS-70541 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only EU RoHS China RoHS ELV and RoHS Compliant REACH SVHC Not Reviewed Halogen-Free Status Not Reviewed Need more information on product environmental compliance? Email productcompliance@molex.com For a multiple part number RoHS Certificate of Compliance, click here Please visit the Contact Us section for any non-product compliance questions. Agency Certification CSA UL LR19980 E29179 General Product Family Series Application Overview Product Name PCB Headers 70575 Wire-to-Board cgrid__sl_products SL™ Physical Breakaway Circuits (Loaded) Circuits (maximum) Color - Resin Durability (mating cycles max) Flammability Glow-Wire Compliant Guide to Mating Part Lock to Mating Part Material - Metal Material - Plating Mating Material - Plating Termination Material - Resin Number of Rows Orientation PC Tail Length (in) PC Tail Length (mm) PCB Locator PCB Retention PCB Thickness Recommended (in) PCB Thickness Recommended (mm) Packaging Type Pitch - Mating Interface (in) Pitch - Mating Interface (mm) Plating min: Mating (µin) Plating min: Mating (µm) Plating min: Termination (µin) Plating min: Termination (µm) Polarized to Mating Part Shrouded Stackable Surface Mount Compatible (SMC) No 7 7 Black 50 94V-0 No Yes Yes Brass, Phosphor Bronze Gold Tin High Temperature Thermoplastic 1 Right Angle 0.130 In 3.30 mm Yes Yes 0.062 In 1.60 mm Tube 0.100 In 2.54 mm 15 0.375 75 1.875 Yes Fully No Yes Search Parts in this Series 70575Series Mates With 70004 Temperature Range - Operating Termination Interface: Style -40°C to +105°C Through Hole Electrical Current - Maximum per Contact Voltage - Maximum 3A 250V Solder Process Data Lead-free Process Capability Wave Capable (TH only) Material Info Reference - Drawing Numbers Packaging Specification Product Specification Sales Drawing PK-70873-0017 PS-70400, PS-70541 SDA-70575-**** This document was generated on 05/31/2010 PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

下载 PDF

705-75-0041

1. 物料型号： - 型号：0705750041 - 状态：Active（活跃）

2. 器件简介： - 产品系列：PCB Headers（PCB插座） - 产品名称：SLTM - 应用：Wire-to-Board（线对板） - 概述：cgrid sl产品，2.54mm（.100"）间距SLTM插座，单排，直角，.180"口袋，带压配合塑料钉。7电路，0.38um（15u"）金（Au）选择性镀金。

3. 引脚分配： - 电路（已加载）：7 - 最大电路数：7

4. 参数特性： - 颜色 - 树脂耐用性（最大插拔次数）：黑色 - 50次 - 阻燃性：94V-0 - 耐热性：无 - 配合导向：是 - 锁紧到配合部件材料 - 金属：是（黄铜，锡磷青铜） - 镀层 - 配合：金 - 镀层 - 终止：锡 - 树脂编号 - 行数：1 - 方向：直角 - PC尾长（英寸）：0.130英寸 - PCB定位器：是 - PCB保持：是 - 推荐PCB厚度（英寸）：0.062英寸 - 配合界面间距（英寸）：0.100英寸 - 镀层最小值：配合（15u"）0.375um，终止（75u"）1.875um - 对配合部件极化：是 - 带罩：完全 - 可堆叠：否 - 表面安装兼容（SMC）：是

5. 功能详解： - 操作温度范围：-40°C至+105°C - 终止接口风格：通孔 - 每个接触点最大电流：3A - 最大电压：250V - 焊接过程数据：无铅流程能力

6. 应用信息： - 与70004型号配合使用

7. 封装信息： - 包装类型：管装 - 间距 - 配合界面（mm）：2.54mm
