1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0018 General Information Part Number: 76650-0018 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom .093" Power Connector Kit Panel Mount Plug and Receptacle, with Extraction Tool and Universal Crimp Tool Standard .093" (Molex parts within this kit) - EU and China RoHS, UL, CSA, TUV Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The Standard .093" is a durable and economical power or signal connector, capable of carrying up to 12 amps per circuit. Tough Nylon housings and robust terminal design create a durable, long lasting product. The Standard .093" products are reliable and offer high value in features and price. These products are an excellent choice for power or signal interconnect applications. Features and Benefits • Male and female terminals may be used in either plug or receptacle housings • Free hanging or panel mount housing version available • Round terminals may be oriented in any direction for fast assembly Applications • Power Supplies • Appliances • Gaming Machines • Vending Machines • Refrigerators • Washing Machines • Copy Machines Wire to Wire and Panel Mount 5.03mm (.198 ") Plug and Receptacle Panel Mount and Free-hanging 1, 2, 3, 4, 5, 6, 9, 12 and 15 5 to 10 Amps - Dependent on AWG and Circuit Size 250 or 600 Volts 22-18 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0018 Bill of Materials for Part No. 76650-0018 Country Molex Part No. of Origin 02-09-1119 02-09-2118 03-09-1011 03-09-1027 03-09-1041 03-09-1054 03-09-1061 03-09-1081 03-09-1091 03-09-1121 03-09-1151 03-09-2011 03-09-2021 03-09-2031 03-09-2041 03-09-2057 03-09-2061 03-09-2091 03-09-2122 03-09-2159 W-HT-1919^ W-HT-2054^ USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA USA Taiwan USA Quantity in Kit 100 100 25 5 4 3 1 4 1 1 1 25 5 4 4 3 1 1 1 1 1 1 Description .093” Dia. Crimp Female Socket Terminals, 22-18 AWG .093” Dia. Crimp Male Pin Terminals, 22-18 AWG 5.03mm (.198 ") Pitch 1-Circuit Free-hanging Connector Receptacle 5.03mm (.198 ") Pitch 2-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 4-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 5-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 6-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 3-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 9-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 12-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 15-Circuit Panel Mount Connector Receptacle 5.03mm (.198 ") Pitch 1-Circuit Free-hanging Connector Plug 5.03mm (.198 ") Pitch 2-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 3-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 4-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 5-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 6-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 9-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 12-Circuit Panel Mount Connector Plug 5.03mm (.198 ") Pitch 15-Circuit Panel Mount Connector Plug Standard Crimping Tool, Crimps 24-14 AWG Extraction Tool ^ = Tool Provided by Waldom For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0018 Recommended Molex Tool(s) for Part No. 76650-0018* Country Molex Part No. of Origin 83819-1200 * 11-03-0006 * 11-02-0003 * Sweden Hand Crimp Tool Sweden Extraction Tool Sweden Insertion Tool Description *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 3 of 3
