1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0058 General Information Part Number: 76650-0058 Manufacturer: Title: Description: Product Family: Certificates: Country of Origin: Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The Standard .093" is a durable and economical power or signal connector, capable of carrying up to 12 amps per circuit. Tough Nylon housings and robust terminal design create a durable, long lasting product. The Standard .093" products are reliable and offer high value in features and price. These products are an excellent choice for power or signal interconnect applications. Features and Benefits • Male and female terminals may be used in either plug or receptacle housings • Free hanging or panel mount housing version available • Round terminals may be oriented in any direction for fast assembly Applications • Power Supplies • Appliances • Gaming Machines • Vending Machines • Refrigerators • Washing Machines • Copy Machines Wire to Wire 5.03mm (.198 ") Plug and Receptacle Panel Mount 3 5 Amps 600 Volts 22-18 AWG Molex / Waldom .093" Power Connector Kit Single Row Panel Mount Plug and Receptacle, 3 Circuit Standard .093" (Molex parts within this kit) - EU and China RoHS, UL, CSA and TUV Kit assembled in U.S.A. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0058 Bill of Materials for Part No. 76650-0058 Molex Part No. 02-09-1119 02-09-2118 03-09-1031 03-09-2031 Country of Origin USA USA USA USA Description .093” Dia. Crimp Female Socket Terminals, 22-18 AWG .093” Dia. Crimp Male Pin Terminals, 22-18 AWG 3-Circuit Panel Mount Nylon Connector Receptacle 3-Circuit Panel Mount Nylon Connector Plug Quantity in Kit 11 11 3 3 Recommended Molex Tool(s) for Part No. 76650-0058* Molex Part No. 63819-1200 * 11-03-0006 * 11-02-0003 * Country of Origin Sweden Hand Crimp Tool Sweden Extraction Tool Sweden Insertion Tool Description *Tools not included in kit. Tools ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
