03-12-1036

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0001 General Information Part Number: 76650-0001 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom HCS-125 Power Connector Kit Single Row Plug and Receptacle with Universal Crimp Tool HCS-125 (Molex Parts within this kit) - EU RoHS Compliant, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights HCS-125 is a high current, economical power pin and socket wire-to-wire power connector. Capable of carrying up to 20 amperes per circuit in a wire-to-wire configuration. These connectors are Dual gender housings, can take either pins or sockets. Features and Benefits • The HCS-125 is an enhanced version of the Molex proven .125" system and meets the need for a connector system rated at greater than the industry standard 12.0A per circuit • Positive locks prevent accidental unmating • Fully isolated terminals protect terminals • Pull tabs Applications • Residential or commercial appliances • HVAC equipment • Computer servers • Networking equipment • Office equipment • Fitness equipment • Medical equipment • Retail Security Scanning Systems Wire-to-Wire 8.38mm (.330") Plugs and Receptacles 1, 2, 3 and 4 (12 and 20) Amps - Dependent on Wire Gauge 600 Volts (18-16) and (14-10) AWG For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0001 Bill of Materials for Part No. 76650-0001 Country Molex Part No. of Origin 03-12-1016 03-12-1026 03-12-1036 03-12-1046 03-12-2016 03-12-2026 03-12-2035 03-12-2045 18-12-1222 18-12-1602 18-12-2222 18-12-2602 CT-4071-1R^ USA USA USA USA USA USA USA USA USA USA USA USA Description 8.38mm (.330") Pitch HCS-125 Receptacle 1 Circuit 8.38mm (.330") Pitch HCS-125 Receptacle 2 Circuit 8.38mm (.330") Pitch HCS-125 Receptacle 3 Circuit 8.38mm (.330") Pitch HCS-125 Receptacle 4 Circuit 8.38mm (.330") Pitch HCS-125 Free Hanging Plug 1 Circuit 8.38mm (.330") Pitch HCS-125 Free Hanging Plug 2 Circuit 8.38mm (.330") Pitch HCS-125 Panel Mount Plug 3 Circuit 8.38mm (.330") Pitch HCS-125 Panel Mount Plug 4 Circuit 3.18mm (.125") Diameter Female Crimp Terminals, 18-16 AWG 3.18mm (.125") Diameter Female Crimp Terminals, 14-10 AWG 3.18mm (.125") Diameter Male Crimp Terminals, 18-16 AWG 3.18mm (.125") Diameter Male Crimp Terminals, 14-10 AWG ^ = Tool Provided by Waldom Quantity in Kit 10 5 5 5 10 5 5 5 25 25 25 25 1 TAIWAN Universal Crimping, Bolt Cutter, Wire Stripping Tool Recommended Molex Tool(s) for Part No. 76650-0001* Country Molex Part No. of Origin 11-03-0008 * 63811-1100 * 63819-1100 * USA Description Extraction Tool (HT-2066-A) Germany Hand Crimper (14-10) Sweden Hand Crimper (18-16) *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 2 of 2
