09-50-3021

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0094 General Information Part Number: 76650-0094 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom KK-156 Connector Kit .156 Pitch Receptacle and Terminals, 2 Circuit KK™ (Molex parts within this kit) - EU and China RoHS Compliant, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The KK system of "building block" connectors can be used to create thousands of different configurations, allowing each user to build a system that is precisely suited to their application. KK has become known as a versatile interconnecting system developed to meet the challenge of modularization. Features and Benefits • Standard cantilever terminals • Cantilever design provides high contact pressure • Wiping action cleans oxides when connector is mated Applications • Vending and Gaming Machines • Production Equipment • Industrial Instruments • Energy and Power Wire-to-Board 3.96mm (.156") Receptacle 2 4.75 Amps 250 Volts 24-18 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0094 Bill of Materials for Part No. 76650-0094 Country Molex Part No. of Origin 08-50-0106 09-50-3021 USA USA Description KK™ Female Crimp Terminals, 24-18 AWG 3.96mm (.156") Pitch KK™ Receptacles 2 Circuit Quantity in Kit 11 5 Recommended Molex Tool(s) for Part No. 76650-0094* Country Molex Part No. of Origin 63811-7500 * 11-03-0016 * Germany Hand Crimp Tool USA Extraction Tool Description *Tools not included in kit. Tools ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
