11-03-0022

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0009 General Information Part Number: 76650-0009 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom KK-100 Connector Kit Vertical and Right Angle Header and Receptacle, with Extraction and Premium Crimp Tool KK™ (Molex parts within this kit) - EU and China RoHS, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The KK system of "building block" connectors can be used to create thousands of different configurations, allowing each user to build a system that is precisely suited to their application. KK has become known as a versatile interconnecting system developed to meet the challenge of modularization. Features and Benefits • Standard cantilever terminals • Cantilever design provides high contact pressure • Wiping action cleans oxides when connector is mated • Locking ramps for improved retention Applications • Vending and Gaming Machines • Production Equipment • Industrial Instruments • Energy and Power Wire-to-Board 2.54mm (.100") Receptacle and Header Vertical and Right Angle 2, 4, 6, 8 and 10 2.5 Amps 250 Volts 30-22 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0009 Bill of Materials for Part No. 76650-0009 Country Molex Part No. of Origin 08-50-0114-C 15-38-1024 22-01-2021 22-01-2041 22-01-2061 22-01-2081 22-01-2101 22-03-2021 22-03-2041 22-03-2061 22-03-2081 22-03-2101 22-05-2021 22-05-2041 22-05-2061 22-05-2081 22-05-2101 W-HT-1884 63811-1000 USA USA USA USA USA USA USA Description KK™ 100 Female Crimp Terminals, 22-30 AWG 2.54mm (.100") Pitch KK™ 100 Shunt/Jumper 2 Circuit 2.54mm (.100") Pitch KK™ 100 Receptacles 2 Circuit 2.54mm (.100") Pitch KK™ 100 Receptacles 4 Circuit 2.54mm (.100") Pitch KK™ 100 Receptacles 6 Circuit 2.54mm (.100") Pitch KK™ 100 Receptacles 8 Circuit 2.54mm (.100") Pitch KK™ 100 Receptacles 10 Circuit Quantity in Kit 100 10 12 6 6 6 6 6 3 3 3 3 6 3 3 3 3 1 1 Mexico 2.54mm (.100") Pitch KK™ 100 Vertical Headers 2 Circuit Mexico 2.54mm (.100") Pitch KK™ 100 Vertical Headers 4 Circuit Mexico 2.54mm (.100") Pitch KK™ 100 Vertical Headers 6 Circuit Mexico 2.54mm (.100") Pitch KK™ 100 Vertical Headers 8 Circuit Mexico 2.54mm (.100") Pitch KK™ 100 Vertical Headers 10 Circuit 2.54mm (.100") Pitch KK™ 100 Right Angle Headers 2 Mexico Circuit 2.54mm (.100") Pitch KK™ 100 Right Angle Headers 4 Mexico Circuit 2.54mm (.100") Pitch KK™ 100 Right Angle Headers 6 Mexico Circuit 2.54mm (.100") Pitch KK™ 100 Right Angle Headers 8 Mexico Circuit 2.54mm (.100") Pitch KK™ 100 Right Angle Headers 10 Mexico Circuit USA USA Extraction Tool Premium Crimping Tool Recommended Molex Tool(s) for Part No. 76650-0009* Country Molex Part No. of Origin 63811-8200 * 11-03-0022 * 63812-0000 * Sweden Hand Crimp Tool Sweden Extraction Tool Sweden Insertion Tool Description *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
