15-92-2250

厂商：
MOLEXKITS
封装：
描述：
15-92-2250 - High Speed I/O Right Angle Plug, Receptacle and Hardware - MolexKits

数据手册：

下载15-92-2250.pdf

立即购买

详情介绍
数据手册
价格&库存

15-92-2250 数据手册

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0145 General Information Part Number: 76650-0145 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom LFH Matrix 50 Connector Kit High Speed I/O Right Angle Plug, Receptacle and Hardware LFH™ Matrix 50 (Molex Parts within this kit) - UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Current Rating: Voltage Rating: Wire size: Product Highlights The Low Force Helix (LFH) contact was designed for high-pin count signal applications where there is a need for reliability and performance. Designed for both cable-to-board and board-to-board applications, the system's low insertion forces make it ideal for situations where multiple single lines need to be terminated or packaged in a limited space. The patented "helix" plug pin interfaces with a split-beam receptacle contact giving a low insertion force with 2-point contact reliability. Rated at 4 Gbps. Features and Benefits • High density contact interface, more terminals in a smaller package • High pin count, flexibility in many different applications • Low mating force, aids in the mating of the final product • Wire termination by weld or solder of terminal sticks, ease of manufacturability and reliability • Shielded, protects signal integrity • High cycle life 5,000 cycles Applications • Mainframe Computers • Mass Storage • Portable POS Units • Network Interface Cards • Routers • Switches • Audio, Video Editing and Storage • Military Data Communication and Video Equipment (cots) • Medical Devices (Wire-to-Board) and (Board-to-Board) 1.27mm (.050") Plugs and Receptacles Right Angle and Vertical 1 Amp 40 Volts 36-28 AWG For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0145 Bill of Materials for Part No. 76650-0145 Country Molex Part No. of Origin 70928-2001 70982-1003 70929-2000 51-24-2021 71629-4000 15-92-2250 USA USA Description 1.27mm (.050") Pitch LFH™ Matrix 50 Receptacle R.A. 60 Circuit Quantity in Kit 1 4 1 4 4 1 Hex Screw (Panel Mount) Jackposts for LFH™ and TDP® 1.27mm (.050") Pitch LFH™ Matrix 50 Plug (Cable) Mexico Subassembly 60 Circuit Mexico LFH™ Terminal Stick with Carrier, 15 Circuits USA USA LFH™ Matrix 50 & 75 Docking Hardware Guide Sleeve 1.27mm (.050") Pitch LFH™ Matrix 50 Plug R.A. 60 Circuit Recommended Molex Tool(s) for Part No. 76650-0145* Country Molex Part No. of Origin 62200-1500 * 62200-1100 * USA USA Description LFH STICK LOAD TOOL LFH STICK PREP TOOL KIT *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 2 of 2

下载 PDF

15-92-2250

1. 物料型号： - 型号：76650-0145 - 制造商：Molex / Waldom

2. 器件简介： - 产品名称：LFH Matrix 50 Connector Kit - 描述：高速I/O直角插头、插座和硬件 - 产品系列：LFH™ Matrix 50 - 认证：UL和CSA认证 - 产地：美国组装

3. 引脚分配： - 配置：线对板（Wire-to-Board）和板对板（Board-to-Board） - 间距：1.27mm（0.050英寸） - 连接器类型：插头和插座 - 安装方向：直角和垂直

4. 参数特性： - 电流额定值：1安培 - 电压额定值：40伏特 - 线规：36-28 AWG

5. 功能详解： - 低力螺旋（LFH）触点设计用于高引脚数信号应用，需要可靠性和性能。 - 适用于电缆到板和板到板应用，系统的低插入力使其适合在有限空间内需要多个单线终止或包装的情况。 - 专利“螺旋”插头销与分束插座接触，提供低插入力和2点接触可靠性。 - 额定4 Gbps。

6. 应用信息： - 高密度接触界面，更小的封装中有更多的端子。 - 高引脚数，适用于多种不同的应用。 - 低配对力，有助于最终产品的配对。 - 通过焊接或焊接端子棒进行线束端接，易于制造和可靠性。 - 屏蔽，保护信号完整性。 - 高周期寿命5000次。 - 应用领域包括大型计算机、大规模存储、便携式POS机、网络接口卡、路由器、交换机、音频、视频编辑和存储、军事数据通信和视频设备（COTS）、医疗设备等。

7. 封装信息： - 1.27mm（0.050英寸）间距LFH™ Matrix 50插座直角60电路 - 1.27mm（0.050英寸）间距LFH™ Matrix 50插头（电缆）60电路 - LFH™终端棒带载体，15电路 - LFH™ Matrix 50 & 75对接硬件导向套
