16-02-0103-C

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0170 General Information Part Number: 76650-0170 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom SL Signal Connector Kit High Vibration Signal Vertical and Right Angle Header and Receptacle. SL™ (Molex Parts within this kit) - EU RoHS Compliant Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire Size: Product Highlights SL (Stackable Linear) is a modular, single row, wire-to-board system, designed for high density signal applications. These are suitable for low power signal applications such as computers, medical instruments, and automotive controls. Wire-to-Board 2.54mm (.100") Headers and Receptacle Right Angle and Vertical 3, 4 and 5 3 Amps 250 Volts 24-22 AWG For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 1 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0170 Features and Benefits • PCB locks hold header in place until permanently soldered • Locking crown secures positive latch to header • Polarization slots guide front ribs of mating connector to prevent pin damage • Standoffs minimize flux retention • Anti-entanglement/overstress ribs prevent discrete wires from catching under latch during harness manufacturing and storage • Front ribs prevent contact damage; the housing cannot be twisted off pins • Dual beam, fully-enclosed box contact • Dual tab strain relief • Locking tang secures terminal in housing Bill of Materials for Part No. 76650-0170 Country Molex Part No. of Origin 16-02-0104-C 16-02-0103-C 50-57-9403 50-57-9404 50-57-9405 70541-0072 70541-0073 70541-0074 15-04-0292 70553-0002 70553-0003 70553-0004 USA USA USA USA USA USA USA USA USA USA USA USA Description SL Cgrid Term Fem Crimp 30u Gold 24-22 AWG SL Cgrid Term Fem Crimp 15u Gold 24-22 AWG 2.54mm (.100") 3 Circuit SL Receptacle G Latch 2.54mm (.100") 4 Circuit SL Receptacle G Latch 2.54mm (.100") 5 Circuit SL Receptacle G Latch 2.54mm (.100") 3 Circuit SL Vertical Header 2.54mm (.100") 4 Circuit SL Vertical Header 2.54mm (.100") 5 Circuit SL Vertical Header Polarizing Key In PC Form B 2.54mm (.100") 3 Circuit SL Right Angle Header 2.54mm (.100") 4 Circuit SL Right Angle Header 2.54mm (.100") 5 Circuit SL Right Angle Header Quantity in Kit 100 100 5 5 5 5 5 5 5 5 5 5 Applications • Automotive: Air bag sensors, Interior lighting, Steering controls, Cigarette lighter, Sound systems • Telecom: Pay phones, LANs, Network equipment, Hubs and switches • Business Machines: Copiers, Printers, Fax machines • Measuring Analyzing Equipment • HVAC Equipment • Large Industrial Equipment • Medical Instrumentation: Surgical, Dental • Computers: Mainframes, Laptops, CD ROMs, Servers, Desktop PCs, Peripherals, Modems, Disk drives Not For Use With C-Grid III™ Components For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 2 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0170 Recommended Molex Tool(s) for Part No. 76650-0170* Country Molex Part No. of Origin 63811-8700 * 11-02-0022 * 11-03-0036 * 63811-8800 * Sweden Hand Crimp Tool USA USA Description Insertion Tool Manual Extraction Tool Sweden Hand Crimp Tool - JAPAN *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 3 of 3
