1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0225 General Information Part Number: 76650-0225 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom Mini-Latch Connector Kit Friction Lock Vertical Header and Receptacle Mini-Latch™ (Molex parts within this kit) - EU and China RoHS Compliant, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current: Voltage: Wire size: Product Highlights Mini-Latch connectors provide a reliable interface for industry-standard 2.50mm (.098" ) wire-to-board applications. The system includes a box-style contact design and housing-side terminal latch to provide protection to the contact area during and after assembly. The durable housing also includes guide rails and molded tabs to facilitate mating and unmating. Features and Benefits • Friction lock provides good mating retention • Box-style contact protects contact area • Polarizing features ensures proper mating • Guide rails and molded ledges facilitates mating and unmating Applications • Data communication equipment • Printers and faxes • PCs and monitors • Automotive Wire-to-Board 2.50mm (.098") Receptacle and Header Vertical 3, 4 and 6 Circuits (1.5 - 3) Amps depending on AWG 250 Volts 28-22 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0225 Bill of Materials for Part No. 76650-0225 Country Molex Part No. of Origin 50802-9101 51191-0300 51191-0400 51191-0600 22-04-1031 22-04-1041 22-04-1061 Japan Japan Japan Japan China China China Description Mini-Latch™ Female Crimp Terminals 28-22 AWG 2.50mm (.098") Pitch Mini-Latch™ Receptacles, 3 Circuits 2.50mm (.098") Pitch Mini-Latch™ Receptacles, 4 Circuits 2.50mm (.098") Pitch Mini-Latch™ Receptacles, 6 Circuits 2.50mm (.098") Pitch Vertical Header 3 Circuits 2.50mm (.098") Pitch Vertical Header 4 Circuits 2.50mm (.098") Pitch Vertical Header 6 Circuits Quantity in Kit 65 5 5 5 5 5 5 Recommended Molex Tool(s) for Part No. 76650-0225* Country Molex Part No. of Origin 63811-5200 * Germany Hand Crimp Tool Description *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
