26-48-1026

1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0208 General Information Part Number: 76650-0208 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom KK-156 Connector Kit .156 Pitch Single Row Vertical and Right Angle Header and Receptacle, 2 Circuit KK™ (Molex parts within this kit) EU and China RoHS, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The KK system of "building block" connectors can be used to create thousands of different configurations, allowing each user to build a system that is precisely suited to their application. KK has become known as a versatile interconnecting system developed to meet the challenge of modularization. Features and Benefits • Standard cantilever terminals • Cantilever design provides high contact pressure • Wiping action cleans oxides when connector is mated • Locking ramps for improved retention when mated Applications • Vending and Gaming Machines • Production Equipment • Industrial Instruments • Energy and Power Wire-to-Board 3.96mm (.156") Receptacle and Header Vertical and Right Angle 2 4 Amps 250 Volts 24-18 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0208 Bill of Materials for Part No. 76650-0208 Country Molex Part No. of Origin 08-50-0106 09-50-3021 26-48-1025 26-48-1026 USA Description Quantity in Kit 7 3 3 3 KK® Crimp Terminals, .156” 24-18 AWG 3.96mm (.156") Pitch KK® Housing Receptacle 2 Circuits (with Locking Ramp) USA 3.96mm (.156") Pitch KK® Vertical Header, Breakaway, 2 Mexico Circuits 3.96mm (.156") Pitch KK® Right Angle Header, Breakaway, Mexico 2 Circuits Recommended Molex Tool(s) for Part No. 76650-0208* Country Molex Part No. of Origin 63811-7500 * 11-03-0016 * Germany Hand Crimp Tool USA Extraction Tool Description *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
