1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0167 General Information Part Number: 76650-0167 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom Mini-SPOX Connector Kit Vertical and Right Angle Header and Receptacle. Mini-Spox™ (Molex Parts within this kit) - EU RoHS Compliant, UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights The name Spox comes from the shape of the terminal, which is like a "spring box". This design style provides multiple points of contact, protects the mating interface area, and prevents fish-hooking from wires during handling. Features and Benefits • Very low profile • Anti-fishhooking design • Box style terminal, multiple contact points and protects pin contact area from contamination during handling • 0.70mm (.027") round pins • Polarization keys, ensure correct mating • Friction locks, secure mating retention • Molded-in pull tabs Applications • Office Automation: Printers, Fax machines, Scanners, Copiers • Telecom: Servers, Hubs, Switches, Routers • Measuring / Analyzing Equipment, Security systems / alarms, Medical monitoring, Lab equipment • Entertainment: Set-top boxes, Car stereos, Video / DVD products • Other applications: Vending machines, Gaming machines, Fitness equipment Wire-to-Board 2.5mm (.098") Headers and Receptacle Vertical and Right Angle 2, 3, 4, 5 and 6 (1.5 - 3) Amps - Dependant on Wire Gauge 250 Volts AC rms / DC 28-22 AWG For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0167 Bill of Materials for Part No. 76650-0167 Country Molex Part No. of Origin 08-70-1040-C 50-37-5023 50-37-5033 50-37-5043 50-37-5053 50-37-5063 22-03-5025 22-03-5035 22-03-5045 22-03-5055 22-03-5065 22-05-7025 22-05-7035 22-05-7045 22-05-7055 22-05-7065 China China China China China China China China China China China China China China China China Description Female Socket Contacts (28-22) AWG 2 CKT 2.5mm Mini-SPOX Housing 3 CKT 2.5mm Mini-SPOX Housing 4 CKT 2.5mm Mini-SPOX Housing 5 CKT 2.5mm Mini-SPOX Housing 6 CKT 2.5mm Mini-SPOX Housing 2 CKT 2.5mm Mini-SPOX Housing Vertical Header 3 CKT 2.5mm Mini-SPOX Housing Vertical Header 4 CKT 2.5mm Mini-SPOX Housing Vertical Header 5 CKT 2.5mm Mini-SPOX Housing Vertical Header 6 CKT 2.5mm Mini-SPOX Housing Vertical Header 2 CKT 2.5mm Mini-SPOX Housing Right Angle Header 3 CKT 2.5mm Mini-SPOX Housing Right Angle Header 4 CKT 2.5mm Mini-SPOX Housing Right Angle Header 5 CKT 2.5mm Mini-SPOX Housing Right Angle Header 6 CKT 2.5mm Mini-SPOX Housing Right Angle Header Quantity in Kit 100 10 8 8 6 6 10 8 8 6 6 10 8 8 6 6 Recommended Molex Tool(s) for Part No. 76650-0167* Country Molex Part No. of Origin 63811-5200 * 63813-1400 * 11-26-0167 * Germany Hand Crimp Tool USA Description Manual Extraction Tool Germany Hand Crimp Tool JHTR5974 - JAPAN *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 2 of 2
