1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0126 General Information 76650-0126 Part Number: Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom PicoBlade Connector Kit SMT Friction Lock Vertical Header and Receptacle PicoBlade™ (Molex Parts within this kit) - UL and CSA Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire size: Product Highlights 1.25mm (.049") pitch PicoBlade™ system is designed for high-density harness applications. PicoBlade provides the same 1.0 amperes of current as similar 2.00mm (.079") pitch systems, but in a more compact design. PicoBlade™ is offered in wire-to-board and wire-to-wire options. The system saves about 45% of PCB space compared to typical 2.00mm wire-to-board systems. It is a single row system, available in 2 to 15 circuits, with both surface mount and through-hole headers. Features and Benefits • Reliable terminal for solid electrical connection • Friction lock for good mating retention • Polarizing features ensures proper mating orientation • Two solder tabs for better connection to the PCB Applications • Car Radios • Process controls • Cash dispensers • Patient monitors • Alarm systems • Set top boxes • Dvd players Wire-to-Board 1.25mm (.049") Headers and Receptacles Vertical 2, 3, 4, 6 and 8 1 Amp 125 Volts 32-28 AWG For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 1 of 2 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0126 Bill of Materials for Part No. 76650-0126 Country Molex Part No. of Origin 50058-8000 51021-0200 51021-0300 51021-0400 51021-0600 51021-0800 53398-0271 53398-0371 53398-0471 53398-0671 53398-0871 Japan Japan Japan Japan Japan Japan Japan Japan Japan Japan Japan Description PicoBlade™ Crimp Terminal, Female, 32-28 AWG 1.25mm (.049") Pitch PicoBlade™ Receptacle, 2 Circuits 1.25mm (.049") Pitch PicoBlade™ Receptacle, 3 Circuits 1.25mm (.049") Pitch PicoBlade™ Receptacle, 4 Circuits 1.25mm (.049") Pitch PicoBlade™ Receptacle, 6 Circuits 1.25mm (.049") Pitch PicoBlade™ Receptacle, 8 Circuits 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 2 Circuits 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 3 Circuits 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 4 Circuits 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 6 Circuits 1.25mm (.049") Pitch PicoBlade™ Header, Surface Mount, Vertical, 8 Circuits Quantity in Kit 100 10 10 10 10 10 10 10 10 10 10 Recommended Molex Tool(s) for Part No. 76650-0126* Country Molex Part No. of Origin 63819-0400 * 11-03-0043 * Sweden Hand Crimp Tool USA Extraction Tool Description *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com Page 2 of 2
