1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0177 General Information Part Number: 76650-0177 Manufacturer: Title: Description: Product Family: Certificates: Molex / Waldom C-Grid III Connector Kit Single Row Vertical Header and Receptacle C-Grid III™ (Molex Parts within this kit) - EU RoHS Compliant Country of Origin: Kit assembled in U.S.A. Specifications Design Configuration: Pitch: Connector Type: Mounting Orientation: Circuit Sizes: Current Rating: Voltage: Wire Size: Product Highlights The 3rd generation C-Grid III 2.54mm (.100") pitch post and receptacle interconnection system offers complete design flexibility and modular components that provide the widest range of electronic packaging alternatives. C-Grid III is a highly-versatile 2.54mm interconnection system offering unique design features: Surface Treatment (platings), Flexibility, Advantage by Design (same mating concept with all termination techniques), Interchangeability (fully compatible with the industry standard DIN41651 as well as the French norm HE-13/14), and Lower Applied Cost. Wire-to-Board 2.54mm (.100") Receptacles and Headers Vertical 2, 3, 4, 5, 6 and 8 3 Amps 350 Volts 24-22 AWG Features and Benefits Applications For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 1 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0177 • Easy breakaway to smaller sizes • High pin retention • Polarized housings • High mechanical stability after soldering • Fully enclosed contact box • Friction Lock housings • Contact and plating orientation according to DIN 41651 • North/south contact orientation avoids overstress Bill of Materials for Part No. 76650-0177 Country Molex Part No. of Origin 90119-2109 90156-0142 90156-0143 90156-0144 90156-0145 90156-0146 90156-0148 90120-0122 90120-0123 90120-0124 90120-0125 90120-0126 90120-0128 69008-0140 Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland Ireland USA Description C-Grid III™ Female Crimp Terminals 24-22 AWG 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 2 Circuit 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 3 Circuit 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 4 Circuit 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 5 Circuit 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 6 Circuit 2.54mm (.100") Pitch C-Grid III™ Receptacle Single Row, 8 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 2 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 3 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 4 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 5 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 6 Circuit 2.54mm (.100") Pitch C-Grid III™ Header, Single Row, Vertical, 8 Circuit C-Grid Insertion Tool Quantity in Kit 50 5 5 4 4 3 3 5 5 4 4 3 3 1 • Automotive: Air bag sensors, Steering controls, Sound systems • Computers and Servers • Business Machines: Copiers, Printers, Fax machines • Measuring Analyzing Equipment • Large Industrial Equipment • Medical Instrumentation: Surgical, Dental, Laboratory Devices Not For Use With Molex SL™ Components Recommended Molex Tool(s) for Part No. 76650-0177* For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 2 of 3 1801 Morgan Street Rockford, Illinois 61102 800-435-2931 www.molexkits.com Datasheet for 76650-0177 Country Molex Part No. of Origin 69008-0003 * 63819-0200 * Netherlands Description Extraction Aid Sweden Hand Crimp Tool *Tool(s) not included in kit. Tool(s) ordered separately. For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com Page 3 of 3
