E_D-1W & F_D-1W Series 1W, FIXED INPUT, ISOLATED & UNREGULATED DUAL/SINGLE OUTPUT DC-DC CONVERTER Multi-country patent protection RoHS FEATURES ● High Efficiency up to 80% ● High Density, High Stability ● 3000VDC Isolation ● DIP Package ● Internal SMD construction ● No Heat sink Required ● Temperature Range: -40°C ~ +85°C ● No External Component Required ● Industry Standard Pinout ● RoHS Compliance PRODUCT PROGRAM Input Part Number F0305D-1W E0505D-1W E0509D-1W E0512D-1W E0515D-1W F0503D-1W F0505D-1W F0509D-1W F0512D-1W 5 4.5-5.5 Voltage (VDC) Nominal 3.3 Range 3.0-3.6 Voltage (VDC) 5 ±5 ±9 ±12 ±15 3.3 5 9 12 15 ±5 ±9 ±12 12 10.8-13.2 ±15 5 9 12 15 15 13.5-16.5 5 ±5 ±9 ±12 24 21.6-26.4 ±15 5 9 12 15 Output Current (mA) M ax. 200 ±100 ±56 ±42 ±33 303 200 111 83 67 ±100 ±56 ±42 ±33 200 111 83 67 200 ±100 ±56 ±42 ±33 200 111 83 67 Min. 20 ±10 ±6 ±5 ±4 30 20 12 9 7 ±10 ±6 ±5 ±4 20 12 9 7 20 ±10 ±6 ±5 ±4 20 12 9 7 74 71 77 77 79 73 72 76 79 78 73 77 80 80 70 75 78 79 69 73 77 80 80 71 76 78 80 UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE UL CE Efficiency Certificate (%, Typ.) APPLICATIONS The E_D-1W & F_D-1W Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) W here the voltage of the input power supply is fixed (voltage variation ≤ ±10%); 2) Where isolation is necessary between input and output (isolation voltage ≤3000VDC); 3) W here the regulation of the output voltage and the output ripple noise are not demanding. Such as: purely digital circuits, ordinary low frequency analog circuits, and IGBT power device driving circuits. F0515D-1W E1205D-1W E1209D-1W E1212D-1W E1215D-1W F1205D-1W F1209D-1W F1212D-1W F1215D-1W F1505D-1W E2405D-1W E2409D-1W E2412D-1W E2415D-1W F2405D-1W F2409D-1W F2412D-1W F2415D-1W MODEL SELECTION E0505D-1W Rated Power Package Style Output Voltage Input Voltage Product Series COMMON SPECIFICATIONS Item Storage humidity range Operating Temp. Range Storage Temp. Range Temp. rise at full load Lead temperature Cooling 1.5mm from case for 10 seconds -40 -55 15 Test conditions Min. Typ. M ax. 95 85 125 25 300 Free air convection Plastic (UL94-V0) 1 3500 2.1 S K hours g °C Units % MORNSUN Science & Technology co.,Ltd. Address: 2th floor 6th building, Huangzhou Industrial District, Guangzhou, China Tel: 86-20-38601850 Fax: 86-20-38601272 http://www.mornsun-power.com Case material Short circuit protection* MTBF W eight * Supply voltage must be discontinued at the end of short circuit duration. T he copyright and authority for the interpretation of the products are reserved by Mornsun Specifications subject to change without notice. E_D-1W & F_D-1W A/2-2009 Page 1 of 3 ISOLATION SPECIFICATIONS Item I solation voltage I solation resistance Test conditions Tested for 1 minute and 1 mA max Test at 500VDC Min. 3000 1000 Typ. Max. Units VDC MΩ TYPICAL CHARACTERISTICS OUTPUT SPECIFICATIONS Item Output power Line regulation For Vin change of ±1% (3.3V output) (Others output) (3.3V output) (5V output) Load regulation 10% to 100% load (9V output) (12V output) (15V output) Output voltage accuracy Temperature drift Ripple& Noise* 100% full load 20MHz Bandwidth(EXXXXD-1W) 20MHz Bandwidth(FXXXXD-1W) 50 75 100 12 10 8.3 6.8 6.3 Test conditions Min 0.1 Typ Max 1 ±1.5 ±1.2 20 15 15 15 15 ±0.03 75 100 %/°C mVp-p KHz Operating Temp.(oC) Units W % See tolerance envelope graph Switching frequency Full load, nominal input *Test ripple and noise by “parallel cable” method. See detailed operation instructions at Testing of Power Converter section, application notes. Note: Dual output models unbalanced load: ±5%. APPLICATION NOTE RECOMMENDED CIRCUIT Dual O utput L +Vo Cout Cin GND Single O utput L Vin Cin GND Requirement on output load To ensure this module can operate efficiently and reliably, During operation, the minimum output load is not less than 10% of the full load, and that this product s hould never be operated under no load! If the actual output power is very small, please connect a resistor with proper resistance at the output end in parallel to increase the load, or use our company’s products with a lower rated output power. L Vin DC DC L Cout 0V -Vo L +Vo DC DC Cout 0V Recommended circuit If you want to further decrease the input/output ripple, an “LC” filtering network may be connected to the input and output ends of the DC/DC converter, see (Figure 1). It should also be noted that the inductance and the frequency of the “LC” filtering network should be staggered with the DC/DC frequency to avoid mutual interference. However, the capacitance of the output filter capacitor must be proper. If the capacitance is too big, a startup problem m ight arise. For every channel of output, provided the safe and reliable operation is ensured, the recommended capacitance of its filter capacitor sees (Table 1). Single Ou tp ut Vin GND REG REG (Figure 1) D u a l Output Vin GND REG REG + Vo 0V -Vo + Vo DC DC REG DC DC 0V Output Voltage Regulation and Over-voltage Protection Circuit The simplest device for output voltage regulation, over-voltage and over-current protection is a linear voltage regulator with overheat protection that is connected to the input or output end in series (Figure 2). (Figure 2) EXTERNAL CAPACITOR TABLE (TABLE 1) Single Dual Cin Vin Cout Cout Vout Vout (VDC) (uF) (uF) ( uF) ( VDC) (VDC) 3.3/5 4.7 3.3/5 10 4.7 ±5 12 15 24 2.2 2.2 1 9 12 15 4.7 2.2 1 Overload Protection Under normal operating conditions, the output circuit of these products has no protection against overload. The simplest method is to connect a self-recovery fuse in series at the input end or add a circuit breaker to the circuit. ±9 ±12 ±15 2.2 1 0.47 I t’s not recommended t o connect any external capacitor in the application field with less than No parallel connection or plug and play 0.5 watt output. T he copyright and authority for the interpretation of the products are reserved by Mornsun Specifications subject to change without notice. E_D-1W & F_D-1W A/2-2009 Page 2 of 3 OUTLINE DIMENSIONS & PIN CONNECTIONS MECHANICAL DIMENSIONS 20.00 [0.787] RECOMMENDED FOOTPRINT DUAL OUTPUT 14 10.00 [0.394] 1 7 10 9 8 ∅1.00 [∅0.039] 2.54 [0.100] (Side View) SINGLE OUTPUT 7.00 [0.276] 14 10 8 2.54 [0.100] 0.50 [0.020] 4.10 [0.161] 17.78 [0.700] 15.24 [0.600] 1 7 1 7.62 [0.300] 14 0.50 [0.020] 7 0.30 [0.012] (Bottom View) 10 9 8 TUBE OUTLINE DIMENSIONS 12.00 [0.472] ∅1.00 [∅0.039] 2.54 [0.100] Note: Unit:mm[inch] Pin section tolerances: 0.10mm[ 0.004inch] General tolerances: 0.25mm[ 0.010inch] FOOTPRINT DETAILS Single Dual Pin GND GND 1 NC NC 7 +Vo +Vo 8 No Pin 0V 9 0V -Vo 10 Vin Vin 14 NC: No connection 8.60 [0.339] 14.70 [0.579] 0.60 [0.024] 5.30 [0.209] Note: Unit :mm[inch] General tolerances: 0.50mm[ 0.020inch] L=530mm[20.866inch] Tube Quantity: 25pcs L=220mm[8.661inch] Tube Quantity: 10pcs Note: 1. Operation under minimum load will not damage the converter; However, they may not meet all specification listed. 2. All specifications measured at Ta=25 °C, humidity
