F2405S-1W

E_S-1W & F_S-1W Series 1W, FIXED INPUT, ISOLATED & UNREGULATED DUAL/SINGLE OUTPUT DC-DC CONVERTER Multi-country patent protection FEATURES High Efficiency up to 80% 3000VDC Isolation SIP Package Internal SMD construction No Heat sink Required Temperature Range: -40°C to +85°C No External Component Required Industry Standard Pinout RoHS Compliance RoHS PRODUCT PROGRAM Input Part Number F0305S-1W E0505S-1W E0509S-1W E0512S-1W E0515S-1W F0503S-1W F0505S-1W F0509S-1W F0512S-1W F0515S-1W E1205S-1W E1209S-1W E1212S-1W E1215S-1W F1205S-1W F1209S-1W F1212S-1W F1215S-1W F1505S-1W E2405S-1W E2409S-1W E2412S-1W E2415S-1W F2405S-1W F2409S-1W F2412S-1W F2415S-1W 24 21.6-26.4 not 15 13.5-16.5 12 10.8-13.2 5 4.5-5.5 Voltage (VDC) Nominal 3.3 Range 3.0-3.6 Voltage (VDC) 5 ±5 ±9 ±12 ±15 3.3 5 9 12 15 ±5 ±9 ±12 ±15 5 9 12 15 5 ±5 ±9 ±12 ±15 5 9 12 15 Output Current (mA) Max 200 ±100 ±56 ±42 ±33 303 200 111 83 67 ±100 ±56 ±42 ±33 200 111 83 67 200 ±100 ±56 ±42 ±33 200 111 83 67 Min 20 ±10 ±6 ±5 ±4 30 20 12 9 7 ±10 ±6 ±5 ±4 20 12 9 7 20 ±10 ±6 ±5 ±4 20 12 9 7 74 71 77 77 79 73 72 76 79 78 73 77 80 80 70 75 78 79 69 73 77 80 80 71 76 78 80 UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL UL Efficiency (%, Typ) Certificate APPLICATIONS The E_S-1W & F_S-1W Series are specially designed for applications where a group of polar power supplies are isolated from the input power supply in a distributed power supply system on a circuit board. These products apply to: 1) W here the voltage of the input power supply is fixed (voltage variation ≤ ±10%); 2) W here isolation is necessary between input and output (isolation voltage ≤3000VDC); 3) W here the regulation of the output voltage and the output ripple noise are demanding. Such as: purely digital circuits, ordinary low frequency analog circuits, and IGBT power device driving circuits. MODEL SELECTION Note: The E_S-W25/F_S-W25 series also are available in our company. E0505S-1W Rated Power Package Style Output Voltage Input Voltage Product Series COMMON SPECIFICATIONS I tem Operating Temp. Range Storage Temp. Range Storage humidity range Cooling Temp. rise at full load Lead temperature I solation voltage I solation resistance Short circuit protection* Case material MTBF W eight *supply voltage must be discontinued at the end of short circuit duration. Test conditions Min -40 -55 Typ Max 85 125 95 Units °C % Free air convection 15 1.5mm from case for 10 seconds Tested for 1 minute and 1 mA max Test at 500VDC 3000 1000 1 Plastic (UL94-V0) 3500 2.1 K hours g 25 300 °C VDC MΩ s MORNSUN Science& Technology co.,Ltd. Address: 2th floor 6th building, Hangzhou Industrial District, Guangzhou, China Tel: 86-20-38601850 Fax: 86-20-38601272 http://www.mornsun-power.com MORNSUN reserves the copyright Specifications subject to change without notice. E_S-1W & F_S-1W A/1-2007 Page 1 of 2 OUTPUT SPECIFICATIONS Item Output power Line regulation For Vin change of ±1% (3.3 input) (others input) (3.3 output) (5V output) Load regulation 10% to 100% load (9V output) (12V output) (15V output) Output voltage accuracy Temperature drift 100% full load (EXXXXS-1W ） Test conditions Min 0.1 Typ Max 1 ±1.5 ±1.2 Units W Overload Protection Under normal operating conditions, the output circuit of these products has no protection against overload. The simplest method is to connect a self-recovery fuse in series at the input end or add a circuit breaker to the circuit. 12 10 8.3 6.8 6.3 20 15 15 15 15 0.03 %/°C % Recommended circuit If you want to further decrease the input/output ripple, an “LC” filtering network may be connected to the input and output ends of the DC/DC converter, see (Figure 1). Dual Output L L See tolerance envelope graph 50 100 75 100 100 75 150 100 150 KHz mVp-p Vin Cin +Vo Cout Ripple& Noise* 20MHz Bandwidth (EXX24S-1W ） (FXXXXS-1W ） ( FXX24S-1W ） DC DC GND Single Output L L Cout 0V -Vo L Switching frequency Full load, nominal input Vin Cin +Vo Cout *Test ripple and noise by “parallel cable” method. See detailed operation instructions at Testing of Power Converter section, application notes. Note: 1.All specifications measured at TA=25°C, humidity
