DEHR33D681KA3B

Reference Specification DEH Series High Temperature Low Loss Lead Type Disc Ceramic Capacitors of class 2 for General Purpose Product specifications in this catalog are as of Dec. 2017, and are subject to change or obsolescence without notice. Please consult the approval sheet before ordering.Please read rating and Cautions first. Reference only CAUTION 1. OPERATING VOLTAGE When DC-rated capacitors are to be used in AC or ripple current circuits, be sure to maintain the Vp-p value of the applied voltage or the Vo-p which contains DC bias within the rated voltage range. When the voltage is started to apply to the circuit or it is stopped applying, the irregular voltage may be generated for a transit period because of resonance or switching. Be sure to use a capacitor within rated voltage containing these irregular voltage. When DC-rated capacitors are to be used in input circuits from commercial power source (AC filter), be sure to use Safety Recognized Capacitors because various regulations on withstand voltage or impulse withstand established for each equipment should be taken into considerations. Voltage Positional Measurement DC Voltage Vo-p DC+AC Voltage Vo-p AC Voltage Vp-p Pulse Voltage(1) Pulse Voltage(2) Vp-p Vp-p 2. OPERATING TEMPERATURE AND SELF-GENERATED HEAT Keep the surface temperature of a capacitor below the upper limit of its rated operating temperature range. Be sure to take into account the heat generated by the capacitor itself. When the capacitor is used in a high-frequency current, pulse current or the like, it may have the selfgenerated heat due to dielectric-loss. The allowable frequency should be in less than 300kHz in sine wave. Applied voltage should be the load such as self-generated heat is within 20 C on the condition of atmosphere temperature 25 C. When measuring, use a thermocouple of small thermal capacity-K of 0.1mm and be in the condition where capacitor is not affected by radiant heat of other components and wind of surroundings. (Never attempt to perform measurement with the cooling fan running. Otherwise, accurate measurement cannot be ensured.) 3. FAIL-SAFE When capacitor would be broken, failure may result in a short circuit. Be sure to provide an appropriate fail-safe function like a fuse on your product if failure would follow an electric shock, fire or fume. EGD22E 1 / 20 Reference only 4. LOAD REDUCTION AND SELF-GENERATED HEAT DURING APPLICATION OF HIGH-FREQUENCY AND HIGH-VOLTAGE Since the heat generated by the low-dissipation capacitor itself is low, its allowable power is much higher than the general B characteristic. However, in case such an applied load that the self-heating temperature is 20 C at the rated voltage, the allowable power may be exceeded. Therefore, when using the low-dissipation capacitors in a high-frequency and high-voltage circuit with a frequency of 1kHz or higher, make sure that the Vp-p values including the DC bias, do not exceed the applied voltage value specified in Table 1. Also make sure that the self-heating temperature (the difference between the capacitor’s surface temperature and the capacitor’s ambient temperature) at an ambient temperature of 25 C does not exceed the value specified in Table 1. As shown in Fig. 2, the self-heating temperature depends on the ambient temperature. Therefore, if you are not able to set the ambient temperature to approximately 25 C, please contact our sales representatives or product engineers. Allowable Conditions at High-frequency Temp. DC Rated Char. Voltage Allowable Conditions at High-frequency *3 R 250V Applied Voltage (max.) 250Vp-p C 500V 500Vp-p 20 C max. 800Vp-p 20 C max. 1kV R 2kV 3.15kV Self-heating Temp. (25 C Ambient Temp.) *1 10 C max. 1000Vp-p 5 C max. 1400Vp-p 20 C max. 2000Vp-p 5 C max. 1600Vp-p 20 C max. Capacitor’s Ambient Temp. *2 -25 to +85 C 3150Vp-p 5 C max. *1 Fig. 1 shows the relationship between the applied voltage and the allowable self-heating temperature regarding 1 to 3.15kV rated voltage of the DEH series R characteristic. *2 When the ambient temperature is 85 to 125 C, the applied voltage needs to be further reduced. If the low-dissipation capacitors needs to be used at an ambient temperature of 85 to 125 C, please contact our sales representatives or product engineers. *3 Fig. 3 shows reference data on the allowable voltage-frequency characteristic for a sine wave voltage. Relationship Between Applied Voltage and Self-heating Temperature Allowable Self-heating Temp. at 25 C Ambient Temp.  Dependence of Self-heating Temperature on Ambient Temperature EGD22E 2 / 20 Reference only Allowable Voltage (Sine Wave Voltage) – Frequency Characteristic At Ambient Temperature of 85 C or less Because of the influence of harmonics, when the applied voltage is a rectangular wave or pulse wave voltage (instead of a sine wave voltage), the heat generated by the capacitor is higher than the value obtained by application of the sine wave with the same fundamental frequency. Roughly calculated for reference, the allowable voltage for a rectangular wave or pulse wave corresponds approximately to the allowable voltage for a sine wave whose fundamental frequency is twice as large as that of the rectangular wave or pulse wave. This allowable voltage, however, varies depending on the voltage and current waveforms. Therefore, you are requested to make sure that the self-heating temperature is not higher than the value specified in Table 1. 5. VIBRATION AND IMPACT Do not expose a capacitor or its leads to excessive shock or vibration during use. 6. SOLDERING When soldering this product to a PCB/PWB, do not exceed the solder heat resistance specification of the capacitor. Subjecting this product to excessive heating could melt the internal junction solder and may result in thermal shocks that can crack the ceramic element. When soldering capacitor with a soldering iron, it should be performed in following conditions. Temperature of iron tip : 400 C max. Soldering iron wattage : 50W max. Soldering time : 3.5 s max. 7. BONDING, RESIN MOLDING AND COATING In case of bonding, molding or coating this product, verify that these processes do not affect the quality of capacitor by testing the performance of the bonded, molded or coated product in the intended equipment. In case of the amount of applications, dryness / hardening conditions of adhesives and molding resins containing organic solvents (ethyl acetate, methyl ethyl ketone, toluene, etc.) are unsuitable, the outer coating resin of a capacitor is damaged by the organic solvents and it may result, worst case, in a short circuit. The variation in thickness of adhesive, molding resin or coating may cause a outer coating resin cracking and/or ceramic element cracking of a capacitor in a temperature cycling. EGD22E 3 / 20 Reference only 8. TREATMENT AFTER BONDING, RESIN MOLDING AND COATING When the outer coating is hot (over 100 ℃) after soldering, it becomes soft and fragile. So please be careful not to give it mechanical stress. Failure to follow the above cautions may result, worst case, in a short circuit and cause fuming or partial dispersion when the product is used. 9. OPERATING AND STORAGE ENVIRONMENT The insulating coating of capacitors does not form a perfect seal; therefore, do not use or store capacitors in a corrosive atmosphere, especially where chloride gas, sulfide gas, acid, alkali, salt or the like are present. And avoid exposure to moisture. Before cleaning, bonding, or molding this product, verify that these processes do not affect product quality by testing the performance of a cleaned, bonded or molded product in the intended equipment. Store the capacitors where the temperature and relative humidity do not exceed -10 to 40 C and 15 to 85%. Use capacitors within 6 months after delivered. Check the solderability after 6 months or more. 10. LIMITATION OF APPLICATIONS Please contact us before using our products for the applications listed below which require especially high reliability for the prevention of defects which might directly cause damage to the third party’s life, body or property. 1. Aircraft equipment 2. Aerospace equipment 3. Undersea equipment 4. Power plant control equipment 5. Medical equipment 6. Transportation equipment (vehicles, trains, ships, etc.) 7. Traffic signal equipment 8. Disaster prevention / crime prevention equipment 9. Data-processing equipment exerting influence on public 10. Application of similar complexity and/or reliability requirements to the applications listed in the above. NOTICE 1. CLEANING (ULTRASONIC CLEANING) To perform ultrasonic cleaning, observe the following conditions. Rinse bath capacity : Output of 20 watts per liter or less. Rinsing time : 5 min maximum. Do not vibrate the PCB/PWB directly. Excessive ultrasonic cleaning may lead to fatigue destruction of the lead wires. 2. CAPACITANCE CHANGE OF CAPACITORS - Class 1 capacitors Capacitance might change a little depending on a surrounding temperature or an applied voltage. Please contact us if you use for the strict time constant circuit. - Class 2 and 3 capacitors Class 2 and 3 capacitors like temperature characteristic B, E and F have an aging characteristic, whereby the capacitor continually decreases its capacitance slightly if the capacitor leaves for a long time. Moreover, capacitance might change greatly depending on a surrounding temperature or an applied voltage. So, it is not likely to be able to use for the time constant circuit. Please contact us if you need a detail information. NOTE 1.Please make sure that your product has been evaluated in view of your specifications with our product being mounted to your product. 2.You are requested not to use our product deviating from this specification. EGD22E 4 / 20 Reference only 1. Application This specification is applied to High Temperature Low Loss Lead Type Disc Ceramic Capacitors of Class 2 of DEH series used for General Electric equipment. Do not use these products in any automotive power train or safety equipment including battery chargers for electric vehicles and plug-in hybrids. 2. Rating 2-1. Operating temperature range -25  +125C 2-2. Part number configuration ex.) DEH Series R3 Temperature characteristic 3F 102 Rated Capacitance voltage K B3 B Capacitance Lead Packing Individual tolerance code style code specification Temperature characteristic Code Temperature characteristic R3 R Please confirm detailed specification on  Specification and test methods .  Rated voltage Code 3D 3F Rated voltage DC2kV DC3.15kV  Capacitance The first two digits denote significant figures ; the last digit denotes the multiplier of 10 in pF. ex.) In case of 102. 10102 = 1000pF  Capacitance tolerance Please refer to  Part number list .  Lead code Code Lead style Vertical crimp long type A Straight long type C Vertical crimp short type B Straight short type D Vertical crimp taping type N Straight taping type P  Please refer to  Part number list . Solder coated copper wire is applied for termination.  Packing style code Code B A Packing type Bulk type Ammo pack taping type  Individual specification In case part number cannot be identified without ‘individual specification’ , it is added at the end of part number. 5 / 20 Reference only 3. Marking High temperature guaranteed code Temperature characteristic Nominal capacitance Capacitance tolerance Rated voltage Company name code Manufacturing date : HR : Letter code : 3 digit system : Code : Letter code(In case of DC3.15kV, marked with 3KV) : Abbreviation (Omitted for maximum body diameter  9mm and under) : Abbreviation ex.) YEAR 2010 0D  MONTH 12(December)  From January to September : “1” to “9”, October : “O” , November : “N” , December : “D” (Example) 6 / 20 Reference only 4. Part number list Unit : mm T.C. Cap. Cap. (pF) Dimension (mm) tol. Customer Part Number Murata Part Number DC Rated Volt. (V) D T F d Lead Code Pack qty. (pcs) R 220 ±10% DEHR33D221KC3B 2000 7.0 5.0 7.5 0.6 C3 250 R 270 ±10% DEHR33D271KC3B 2000 7.0 5.0 7.5 0.6 C3 250 R 330 ±10% DEHR33D331KA3B 2000 8.0 5.0 7.5 0.6 A3 250 R 390 ±10% DEHR33D391KA3B 2000 8.0 5.0 7.5 0.6 A3 250 R 470 ±10% DEHR33D471KA3B 2000 9.0 5.0 7.5 0.6 A3 250 R 560 ±10% DEHR33D561KA3B 2000 9.0 5.0 7.5 0.6 A3 250 R 680 ±10% DEHR33D681KA3B 2000 10.0 5.0 7.5 0.6 A3 250 R 820 ±10% DEHR33D821KA3B 2000 11.0 5.0 7.5 0.6 A3 250 R 1000 ±10% DEHR33D102KA3B 2000 12.0 5.0 7.5 0.6 A3 200 R 1200 ±10% DEHR33D122KA3B 2000 12.0 5.0 7.5 0.6 A3 200 R 1500 ±10% DEHR33D152KA3B 2000 12.0 5.0 7.5 0.6 A3 200 R 1800 ±10% DEHR33D182KA3B 2000 14.0 5.0 7.5 0.6 A3 200 R 2200 ±10% DEHR33D222KA3B 2000 15.0 5.0 7.5 0.6 A3 100 R 2700 ±10% DEHR33D272KA3B 2000 17.0 5.0 7.5 0.6 A3 100 R 3300 ±10% DEHR33D332KA4B 2000 19.0 5.0 10.0 0.6 A4 50 R 3900 ±10% DEHR33D392KA4B 2000 20.0 5.0 10.0 0.6 A4 50 R 4700 ±10% DEHR33D472KA4B 2000 21.0 5.0 10.0 0.6 A4 50 R 150 ±10% DEHR33F151KC3B 3150 7.0 6.0 7.5 0.6 C3 250 R 180 ±10% DEHR33F181KC3B 3150 7.0 6.0 7.5 0.6 C3 250 R 220 ±10% DEHR33F221KC3B 3150 7.0 6.0 7.5 0.6 C3 250 R 270 ±10% DEHR33F271KC3B 3150 7.0 6.0 7.5 0.6 C3 250 R 330 ±10% DEHR33F331KA3B 3150 8.0 6.0 7.5 0.6 A3 250 R 390 ±10% DEHR33F391KA3B 3150 9.0 6.0 7.5 0.6 A3 250 R 470 ±10% DEHR33F471KA3B 3150 10.0 6.0 7.5 0.6 A3 250 R 560 ±10% DEHR33F561KA3B 3150 10.0 6.0 7.5 0.6 A3 250 R 680 ±10% DEHR33F681KA3B 3150 11.0 6.0 7.5 0.6 A3 250 R 820 ±10% DEHR33F821KA3B 3150 12.0 6.0 7.5 0.6 A3 200 7 / 20 Reference only Unit : mm T.C. Cap. Cap. (pF) tol. Customer Part Number Murata Part Number Dimension (mm) DC Rated Volt. (V) D T F d Lead Code Pack qty. (pcs) R 1000 ±10% DEHR33F102KA3B 3150 13.0 6.0 7.5 0.6 A3 200 R 1200 ±10% DEHR33F122KA3B 3150 14.0 6.0 7.5 0.6 A3 200 R 1500 ±10% DEHR33F152KA3B 3150 15.0 6.0 7.5 0.6 A3 100 R 1800 ±10% DEHR33F182KA3B 3150 16.0 6.0 7.5 0.6 A3 100 R 2200 ±10% DEHR33F222KA3B 3150 17.0 6.0 7.5 0.6 A3 100 R 2700 ±10% DEHR33F272KA4B 3150 19.0 6.0 10.0 0.6 A4 50 8 / 20 Reference only Unit : mm T.C. Cap. Cap. (pF) tol. Customer Part Number Murata Part Number Dimension (mm) DC Rated Volt. (V) D T F d Lead Code Pack qty. (pcs) R 220 ±10% DEHR33D221KD3B 2000 7.0 5.0 7.5 0.6 D3 500 R 270 ±10% DEHR33D271KD3B 2000 7.0 5.0 7.5 0.6 D3 500 R 330 ±10% DEHR33D331KB3B 2000 8.0 5.0 7.5 0.6 B3 500 R 390 ±10% DEHR33D391KB3B 2000 8.0 5.0 7.5 0.6 B3 500 R 470 ±10% DEHR33D471KB3B 2000 9.0 5.0 7.5 0.6 B3 500 R 560 ±10% DEHR33D561KB3B 2000 9.0 5.0 7.5 0.6 B3 500 R 680 ±10% DEHR33D681KB3B 2000 10.0 5.0 7.5 0.6 B3 500 R 820 ±10% DEHR33D821KB3B 2000 11.0 5.0 7.5 0.6 B3 500 R 1000 ±10% DEHR33D102KB3B 2000 12.0 5.0 7.5 0.6 B3 250 R 1200 ±10% DEHR33D122KB3B 2000 12.0 5.0 7.5 0.6 B3 250 R 1500 ±10% DEHR33D152KB3B 2000 12.0 5.0 7.5 0.6 B3 250 R 1800 ±10% DEHR33D182KB3B 2000 14.0 5.0 7.5 0.6 B3 250 R 2200 ±10% DEHR33D222KB3B 2000 15.0 5.0 7.5 0.6 B3 200 R 2700 ±10% DEHR33D272KB3B 2000 17.0 5.0 7.5 0.6 B3 200 R 3300 ±10% DEHR33D332KB4B 2000 19.0 5.0 10.0 0.6 B4 100 R 3900 ±10% DEHR33D392KB4B 2000 20.0 5.0 10.0 0.6 B4 100 R 4700 ±10% DEHR33D472KB4B 2000 21.0 5.0 10.0 0.6 B4 100 R 150 ±10% DEHR33F151KD3B 3150 7.0 6.0 7.5 0.6 D3 500 R 180 ±10% DEHR33F181KD3B 3150 7.0 6.0 7.5 0.6 D3 500 R 220 ±10% DEHR33F221KD3B 3150 7.0 6.0 7.5 0.6 D3 500 R 270 ±10% DEHR33F271KD3B 3150 7.0 6.0 7.5 0.6 D3 500 R 330 ±10% DEHR33F331KB3B 3150 8.0 6.0 7.5 0.6 B3 500 R 390 ±10% DEHR33F391KB3B 3150 9.0 6.0 7.5 0.6 B3 500 R 470 ±10% DEHR33F471KB3B 3150 10.0 6.0 7.5 0.6 B3 500 R 560 ±10% DEHR33F561KB3B 3150 10.0 6.0 7.5 0.6 B3 500 R 680 ±10% DEHR33F681KB3B 3150 11.0 6.0 7.5 0.6 B3 500 R 820 ±10% DEHR33F821KB3B 3150 12.0 6.0 7.5 0.6 B3 250 9 / 20 Reference only Unit : mm T.C. Cap. Cap. (pF) tol. Customer Part Number Murata Part Number Dimension (mm) DC Rated Volt. (V) D T F d Lead Code Pack qty. (pcs) R 1000 ±10% DEHR33F102KB3B 3150 13.0 6.0 7.5 0.6 B3 250 R 1200 ±10% DEHR33F122KB3B 3150 14.0 6.0 7.5 0.6 B3 250 R 1500 ±10% DEHR33F152KB3B 3150 15.0 6.0 7.5 0.6 B3 200 R 1800 ±10% DEHR33F182KB3B 3150 16.0 6.0 7.5 0.6 B3 200 R 2200 ±10% DEHR33F222KB3B 3150 17.0 6.0 7.5 0.6 B3 200 R 2700 ±10% DEHR33F272KB4B 3150 19.0 6.0 10.0 0.6 B4 100 10 / 20 Reference only Unit : mm T.C. Cap. (pF) Cap. tol. Customer Part Number Murata Part Number Dimension (mm) DC Rated volt. (V) D T F d P Lead code Pack qty. (pcs) R 220 ±10% DEHR33D221KP3A 2000 7.0 5.0 7.5 0.6 15.0 P3 900 R 270 ±10% DEHR33D271KP3A 2000 7.0 5.0 7.5 0.6 15.0 P3 900 R 330 ±10% DEHR33D331KN3A 2000 8.0 5.0 7.5 0.6 15.0 N3 900 R 390 ±10% DEHR33D391KN3A 2000 8.0 5.0 7.5 0.6 15.0 N3 900 R 470 ±10% DEHR33D471KN3A 2000 9.0 5.0 7.5 0.6 15.0 N3 900 R 560 ±10% DEHR33D561KN3A 2000 9.0 5.0 7.5 0.6 15.0 N3 900 R 680 ±10% DEHR33D681KN3A 2000 10.0 5.0 7.5 0.6 15.0 N3 900 R 820 ±10% DEHR33D821KN3A 2000 11.0 5.0 7.5 0.6 15.0 N3 900 R 1000 ±10% DEHR33D102KN3A 2000 12.0 5.0 7.5 0.6 15.0 N3 900 R 1200 ±10% DEHR33D122KN3A 2000 12.0 5.0 7.5 0.6 15.0 N3 900 R 1500 ±10% DEHR33D152KN3A 2000 12.0 5.0 7.5 0.6 15.0 N3 900 R 1800 ±10% DEHR33D182KN7A 2000 14.0 5.0 7.5 0.6 30.0 N7 500 R 2200 ±10% DEHR33D222KN7A 2000 15.0 5.0 7.5 0.6 30.0 N7 500 R 2700 ±10% DEHR33D272KN7A 2000 17.0 5.0 7.5 0.6 30.0 N7 500 R 150 ±10% DEHR33F151KP3A 3150 7.0 6.0 7.5 0.6 15.0 P3 900 R 180 ±10% DEHR33F181KP3A 3150 7.0 6.0 7.5 0.6 15.0 P3 900 R 220 ±10% DEHR33F221KP3A 3150 7.0 6.0 7.5 0.6 15.0 P3 900 R 270 ±10% DEHR33F271KP3A 3150 7.0 6.0 7.5 0.6 15.0 P3 900 R 330 ±10% DEHR33F331KN3A 3150 8.0 6.0 7.5 0.6 15.0 N3 900 R 390 ±10% DEHR33F391KN3A 3150 9.0 6.0 7.5 0.6 15.0 N3 900 R 470 ±10% DEHR33F471KN3A 3150 10.0 6.0 7.5 0.6 15.0 N3 900 R 560 ±10% DEHR33F561KN3A 3150 10.0 6.0 7.5 0.6 15.0 N3 900 R 680 ±10% DEHR33F681KN3A 3150 11.0 6.0 7.5 0.6 15.0 N3 900 R 820 ±10% DEHR33F821KN3A 3150 12.0 6.0 7.5 0.6 15.0 N3 900 R 1000 ±10% DEHR33F102KN3A 3150 13.0 6.0 7.5 0.6 15.0 N3 900 R 1200 ±10% DEHR33F122KN7A 3150 14.0 6.0 7.5 0.6 30.0 N7 500 R 1500 ±10% DEHR33F152KN7A 3150 15.0 6.0 7.5 0.6 30.0 N7 500 11 / 20 Reference only Unit : mm T.C. Cap. (pF) Cap. tol. Customer Part Number Murata Part Number Dimension (mm) DC Rated volt. (V) D T F d P Lead code Pack qty. (pcs) R 1800 ±10% DEHR33F182KN7A 3150 16.0 6.0 7.5 0.6 30.0 N7 500 R 2200 ±10% DEHR33F222KN7A 3150 17.0 6.0 7.5 0.6 30.0 N7 500 12 / 20 Reference only 5. Specification and test methods No. Item 1 Appearance and dimensions 2 3 4 Marking Dielectric strength Between lead wires Specification No marked defect on appearance form and dimensions. Please refer to [Part number list]. To be easily legible. No failure. Body insulation No failure. Between lead wires 10 000M min. 5 Insulation Resistance (I.R.) Capacitance 6 Dissipation Factor (D.F.) 7 Temperature characteristic Test method The capacitor should be inspected by naked eyes for visible evidence of defect. Dimensions should be measured with slide calipers. The capacitor should be inspected by naked eyes. The capacitor should not be damaged when DC voltage of 200% of the rated voltage are applied between the lead wires for 1 to 5 s. (Charge/Discharge current50mA.) The capacitor is placed in the container with metal balls of diameter 1mm so that each lead wire, shortcircuited, is kept about 2mm off the balls as shown in the figure, and AC1 250V (r.m.s.) is applied for 1 to 5 s About 2mm between capacitor lead Metal balls wires and small metals. (Charge/Discharge current50mA.) The insulation resistance should be measured with DC50050V within 605 s of charging. The capacitance should be measured at 20C with 10.2kHz and AC5V(r.m.s.) max.. The dissipation factor should be measured at 20C with 10.2kHz and AC5V(r.m.s.) max.. The capacitance measurement should be made at each step specified in Table. Within specified tolerance. 0.2% max. T.C. R Temp. char. -25 to +85C +85 to +125C within15% Within+15/-30% Pre-treatment : Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h before measurements. 8 Strength of lead Pull Step 1 2 3 4 5 Temp.(C) 202 -253 202 1252 202 Lead wire should not cut off. Capacitor should not be broken. As shown in the figure at right, fix the body of the capacitor and apply a tensile weight gradually to each lead wire in the radial direction of the capacitor up to 10N and keep it for 101 s. Bending Each lead wire should be subjected to 5N of weight and bent 90 at the point of egress, in one direction, then returned to its original position and bent 90 in the opposite direction at the rate of one bend in 2 to 3 s. 9 Vibration Appearance No marked defect. The capacitor should be firmly soldered to the resistance supporting lead wire and vibrated at a frequency Capacitance Within specified tolerance. range of 10 to 55Hz, 1.5mm in total amplitude, with D.F. 0.2% max. about a 1min rate of vibration change from 10Hz to 55Hz and back to 10Hz. Apply for a total of 6 h; 2 h each in 3 mutually perpendicular directions. 10 Solderability of leads Lead wire should be soldered The lead wire of a capacitor should be dipped into a with uniformly coated on the axial ethanol solution of 25wt% rosin and then into direction over 3/4 of the molten solder for 20.5 s. In both cases the depth of circumferential direction. dipping is up to about 1.5 to 2mm from the root of lead wires. Temp. of solder : 245±5°C Lead Free Solder (Sn-3Ag-0.5Cu) 235±5°C H63 Eutectic Solder * "room condition" Temperature: 15 to 35C, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa ESDEH02A 13 / 20 Reference only No. 11 12 13 14 15 Item Soldering effect Appearance (Non-preheat) Capacitance change Dielectric strength (Between lead wires) Specification No marked defect. Within  10% Soldering effect (On-preheat) No marked defect. Within  10% Appearance Capacitance change Dielectric strength (Between lead wires) Per item 3. Per item 3. Test method The lead wire should be immersed into the melted solder of 35010C up to about 1.5 to 2.0mm from the main body for 3.50.5 s. Pre-treatment : Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h before initial measurements. Post-treatment : Capacitor should be stored for 242 h at *room condition. First the capacitor should be stored at 120+0/-5°C for 60+0/-5 s. Then, as in figure, the lead wires should be immersed solder of 260+0/-5°C up to 1.5 to 2.0mm from the root of terminal for 7.5+0/-1 s. Pre-treatment : Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h before initial measurements. Post-treatment : Capacitor should be stored for 242 h at *room condition. Humidity Appearance No marked defect. Set the capacitor for 500 +24/-0 h at 402C in 90 (Under steady to 95% relative humidity. Capacitance Within 10% state) Pre-treatment : change Capacitor should be stored at 1253C for 1 h, D.F. 0.4% max. then placed at *room condition for 242 h I.R. 1 000M min. before initial measurements. Post-treatment : Capacitor should be stored for 1 to 2 h at *room condition. Humidity loading Appearance No marked defect. Apply the rated voltage for 500 +24/-0 h at 402C in 90 to 95% relative humidity. Capacitance Within 10% change (Charge/Discharge current50mA.) Pre-treatment : D.F. 0.6% max. Capacitor should be stored at 1253C for 1 h, I.R. 1 000M min. then placed at *room condition for 242 h before initial measurements. Post-treatment : Capacitor should be stored for 1 to 2 h at *room condition. Life Appearance No marked defect. Apply a DC voltage of 150% of the rated voltage Capacitance for 1 000 +48/-0 h at 1252C, and relative humidity Within 10% change of 50% max.. D.F. 0.4% max. (Charge/Discharge current50mA.) Pre-treatment : I.R. 2 000M min. Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h before initial measurements. Post-treatment : Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h. * "room condition" Temperature: 15 to 35C, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa ESDEH02A 14 / 20 Reference only No. 16 Item Test method The capacitor should be subjected to 5 temperature cycles. 0.4% max. Step Time Temperature(C) 1 000M min. 1 30 min -253 Per item 3. 2 Room Temp. 3 min 3 30 min +1253 4 Room Temp. 3 min Cycle time : 5 cycle Pre-treatment : Capacitor should be stored at 1253C for 1 h, then placed at *room condition for 242 h before initial measurements. Post-treatment : Capacitor should be stored for 242 h at *room condition. * "room condition" Temperature: 15 to 35C, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa Temperature cycle Appearance Capacitance change D.F. I.R. Dielectric strength (Between lead wires) Specification No marked defect. Within 10% ESDEH02A 15 / 20 Reference only 6.Packing specification Bulk type (Packing style code : B) 1 2 The number of packing = Packing quantity  n The size of packing case and packing way 1 : Please refer to [Part number list]. 2 : Standard n = 20 (bag) Polyethylene bag Partition 270 max. 125 max. 340 max. Note) The outer package and the number of outer packing be changed by the order getting amount. Unit : mm Ammo pack taping type (Packing style code : A)  The tape with capacitors is packed zigzag into a case.  When body of the capacitor is piled on other body under it.  There should be 3 pitches and over without capacitors in leader and trailer. The size of packing case and packing way 240 max. Position of label 340 max. 60 max. Capacitor Hold down tape Base tape Hold down tape upper EKBCDE01 16 / 20 Unit : mm Reference only 7. Taping specification 7-1. Dimension of capacitors on tape Vertical crimp taping type < Lead code : N3 > Pitch of component 15.0mm / Lead spacing 7.5mm Unit : mm Item Code Dimensions Remarks Pitch of component P 15.02.0 Pitch of sprocket hole P0 15.00.3 Lead spacing F 7.51.0 Length from hole center to component center P2 7.51.5 Length from hole center to lead P1 3.751.0 Body diameter D Please refer to [ Part number list ]. Deviation along tape, left or right S 02.0 Carrier tape width W 18.00.5 Position of sprocket hole W1 9.00.5 H0 18.02.0 0 Lead distance between reference and bottom planes Deviation of progress direction They include deviation by lead bend . Deviation of tape width direction 0.51.0 Protrusion length Diameter of sprocket hole D0 4.00.1 Lead diameter d 0.600.05 Total tape thickness t1 0.60.3 Total thickness, tape and lead wire t2 1.5 max. Deviation across tape, front h1 Deviation across tape, rear h2 Portion to cut in case of defect L 11.0 1.0 Hold down tape width W0 11.5 min. Hold down tape position W2 1.51.5 Coating extension on lead e Up to the end of crimp Body thickness T Please refer to [ Part number list ]. They include hold down tape thickness. 2.0 max. 0 ETP1N301A 17 / 20 Reference only Vertical crimp taping type < Lead code : N7 > Pitch of component 30.0mm /Lead spacing 7.5mm Unit : mm Item Code Dimensions Remarks Pitch of component P 30.02.0 Pitch of sprocket hole P0 15.00.3 Lead spacing F 7.51.0 Length from hole center to component center P2 7.51.5 Length from hole center to lead P1 3.751.0 Body diameter D Please refer to [ Part number list ]. Deviation along tape, left or right S 02.0 Carrier tape width W 18.00.5 Position of sprocket hole W1 9.00.5 H0 18.02.0 0 Lead distance between reference and bottom planes Deviation of progress direction They include deviation by lead bend. Deviation of tape width direction 0.51.0 Protrusion length Diameter of sprocket hole D0 4.00.1 Lead diameter d 0.600.05 Total tape thickness t1 0.60.3 Total thickness, tape and lead wire t2 1.5 max. Deviation across tape, front h1 Deviation across tape, rear h2 Portion to cut in case of defect L 11.0 1.0 Hold down tape width W0 11.5 min. Hold down tape position W2 1.51.5 Coating extension on lead e Up to the end of crimp Body thickness T Please refer to [ Part number list ]. They include hold down tape thickness. 2.0 max. 0 ETP1N70101A 18 / 20 Reference only Straight taping type < Lead code : P3 > Pitch of component 15.0mm / Lead spacing 7.5mm Unit : mm Item Code Dimensions Remarks Pitch of component P 15.02.0 Pitch of sprocket hole P0 15.00.3 Lead spacing F 7.51.0 Length from hole center to component center P2 7.51.5 Length from hole center to lead P1 3.751.0 Body diameter D Please refer to [ Part number list ]. Deviation along tape, left or right S 02.0 Carrier tape width W 18.00.5 Position of sprocket hole W1 9.00.5 H 20.01.5 1.0 Lead distance between reference and bottom planes Deviation of progress direction They include deviation by lead bend . Deviation of tape width direction 0.51.0 Protrusion length Diameter of sprocket hole D0 4.00.1 Lead diameter d 0.600.05 Total tape thickness t1 0.60.3 Total thickness, tape and lead wire t2 1.5 max. Deviation across tape, front h1 Deviation across tape, rear h2 Portion to cut in case of defect L 11.0 1.0 Hold down tape width W0 11.5 min. Hold down tape position W2 1.51.5 Coating extension on lead e 3.0 max. Body thickness T Please refer to [ Part number list ]. They include hold down tape thickness. 2.0 max. 0 ETP1P30101A 19 / 20 Reference only 7-2. Splicing way of tape 1) Adhesive force of tape is over 3N at test condition as below. W Hold down tape Base tape 2) Splicing of tape a) When base tape is spliced Base tape should be spliced by cellophane tape. (Total tape thickness should be less than 1.05mm.) Progress direction in production line Hold down tape Base tape About 30 to 50 Cellophane tape No lifting for the direction of progressing Unit : mm b) When hold down tape is spliced Hold down tape should be spliced with overlapping. (Total tape thickness should be less than 1.05mm.) ape are spliced Base tape and adhesive tape should be spliced with splicing tape. 20 to 60 Hold down tape Progress direction in production line Base tape Unit : mm c) When both tape are spliced Base tape and hold down tape should be spliced with splicing tape. 3 ) Missing components There should be no consecutive missing of more than three components. The number of missing components should be not more than 0.5% of total components that should be present in a Ammo pack. ETP2D03 20 / 20 Appendix 添付資料 EU RoHS RoHS指令への対応 This products of the following crresponds to EU RoHS 当製品は以下の欧州RoHSに対応しています。　 (1) RoHS 　EU RoHs 2011/65/EC compliance 　2011/65/EC（改正RoHS指令）に対応 　maximum concentration values tolerated by weight in homogeneous materials 　・1000 ppm maximum Lead 　・1000 ppm maximum Mercury 　・100 ppm maximum Cadmium 　・1000 ppm maximum Hexavalent chromium 　・1000 ppm maximum Polybrominated biphenyls (PBB) 　・1000 ppm maximum Polybrominated diphenyl ethers (PBDE) 　鉛：1000ppm以下 　水銀：1000ppm以下 　カドミウム：100ppm以下 　六価クロム：1000ppm以下 　ポリ臭化ビフェニル(PBB)：1000ppm以下 　ポリ臭化ジフェニルエーテル(PBDE)：1000ppm以下
