LXES15AAA1-100

LXES15AAA1-100 1. Features Bi-directional Protection for the IEC61000-4-2(ESD) ±15kV(air), ±15kV(contact)  Ultra low capacitance (0.05pF)  No distortion  RoHS regulation conformity parts   2. Mechanical details L T (unit : mm) W e g e Mark L W T e g Dimension 1.00±0.05 0.50±0.05 0.33 max 0.20±0.10 0.40 min 3. Schematic 4. Maximum Ratings Parameter Operating Voltage ESD per IEC 61000-4-2 (air) ESD per IEC 61000-4-2 (contact) Operating Temperature Storage Temperature Ratings 15 ±15 -40 to +85 -40 to +85 Units V kV o o C C 1 LXES15AAA1-100 5. Electrical Characteristics (T=25 oC) Parameter Capacitance Conditions Vbias=0V, 1MHz Min Typ 0.05 Max Units pF 6．Typical Characteristic 0.10 0.08 Cline (pF) 0.06 0.04 0.02 0.00 -15 -10 -5 0 VDC (V) 5 10 15 7. Soldering Footprint (unit : mm) c a b Mark a b c Dimension 0.4 1.2 0.5 Notes : this land layout is for reference purpose only. 2 LXES15AAA1-100 7. Taping Specification 1) Dimensions of Tape (Paper tape) Φ1.50 +0.1 0 （in mm） 1.75±0.1 3.50±0.05 8.00±0.2 1.12±0.04 0.62±0.04 2.00±0.04 4.00+0.08 0.5max Feeding direction 2) Dimensions of Reel (in mm) 2±0.5 φ13±0.2 9.0＋1.0 －0 Φ60 Φ180 13.0±1.0 3) Packaging unit: 10,000 pcs / reel Note: 1. This datasheet's specifications are subject to change or our products in it may be discontinued without advance notice. Pleas e check with our sales representatives or product engineers before ordering. 2. This datasheet has only typical specifications because there is no space for detailed specifications. Therefore, please appro ve our product specifications or transact the approval sheet for product specifications before ordering. 3
