OD-S589A

Rev. 1.2 March 11, 2002 OD-S589A/-S589B SMT-InGaAs PIN-Amp Module FEATURES n Surface Mountable. n Small Size Flat Ceramic Package (7.6 x 12.7 x 3 mm). n Operating Speed : OD-S589A (155 Mbps : STM-1/OC3) OD-S589B (622 Mbps : STM-4/OC12) n High Sensitivity. n Differential Outputs. n Internal Supply Bypass Capacitor n Wide Operating Temperature Range : − 40 to + 85°C.. n Detachable Pigtail Interface. n Single Supply Voltage from 3.0 to 3.5V. APPLICATION n n n n Subscriber Loop. Telecommunications. Data Communications. Local Area Networks. ABSOLUTE MAXIMUM RATINGS (Ta=+25°C,unless noted) Parameter Optical Input Power Supply Voltage Operating Temperature Storage Temperature Lead Soldering Temperature Symbol Pin VDD Top Tstg Tsol Unit mW V °C °C °C Min. − − − 40 − 40 − Values Typ. 2 + 5.5 − − +230(30sec) Max. − − + 85 + 85 − Notes reflow soldering OPTICAL / ELECTRICAL CHARACTERISTICS (Ta=+25°C, unless noted) Parameter S ensitivity O ptical Overload Band Width Trans Impedance Operating Voltage R esponsivity Conditions BER = 10 -10 −40 ∼85° C 3dB down Unit d Bm dBm MHz kΩ V A/W OD-S589A Min. Typ Min. − − −3 100 − + 3.0 − − 36 − 32 0 150 44 + 3.3 0 .9 − 35 − − − − + 3.5 − OD-S589B Min. Typ Min. − − −3 500 − + 3.0 − − 31 − 0 600 21 + 3.3 0 .9 − 30 − − − − + 3.5 − D IMENSIONS ( Unit:mm) 7 .62 ± 0 .2 0 .2 1 .27 7 .62 Sales Department, Fiber Optic Devices Division Optical Network Operations Unit, NEC Networks NEC Corporation 1753 Shimonumabe,Nakahara-ku,Kawasaki,Kanagawa 211-8666,Japan Tel:+81-44-435-5412 Fax:+81-44-435-5109 http://networks.nec.co.jp/on/dd/en/ Copyright © 2002 NEC Corporation 1 2.7 ± 0 .2 ± 0 . 13 2 .54 2.9 D ATA SUBJECT TO CHANGE WITHOUT NOTICE NEC Electronics (Europe) GmbH Sales and marketing of semiconductors across Europe Oberratherstr. 4, 40472 Dusseldorf, Germany Tel:+49-211-6503-979 FAX:+49-211-6503-358 USA&CANADA NEC FiberOptech, Inc. 10050 North Wolfe Road, Suite SW1-290 Cupertino, CA 95014,USA Tel: +1-408-863-2000 Fax: +1-408-863-2019
