CRYSTAL CLOCK OSCILLATORS
LVPECL HF/UHF CLOCK (XO)
Data Sheet 0631F Rev. -
AA-X29LXXX Series
Description
The AA-X29LXXX Series of quartz crystal oscillators provides ultra high frequency with LVPECL complementary outputs. The outputs can be disabled for test automation or combining multiple clocks. The device is based on low noise analog harmonic multiplication, and packaged in a miniature, low profile leadless FR4 based package with gold plated pads, which enhances compatibility with PCB material.
Applications and Features
• Ultra High Frequency – 150.0MHz to 500.000MHz • Fiber Channel; 10 GbE; Infiniband; Network Processors; SOHO Routing • High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions • Fast Rise and Fall times • Tight frequency stability - ±20 ppm overall available • RoHS Compliant, Lead Free Construction • Low cost
Creating a Part Number AA - X 29L X X X - FREQ Package Code Overall Frequency Stability, ppm AA 6 pad 7.5x 5.2mm SMD E ±20 F ±25 Input Voltage G ±50 A 3.3V±5% H ±100 B 2.5V±5% 9 Customer specific Enable Option L Enable Low N N/C Temperature Range, °C A 0 to 50 B 0 to 70 C -20 to 70 D -40 to 85 9 Customer specific
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
AA-X29LXXX Series Continued LVPECL HF/UHF CLOCK (XO)
Data Sheet 0631F Rev. -
Absolute Maximum Ratings
Parameter Operating Temperature Range Storage Temperature Range Supply Voltage Enable/Disable Voltage Parameter Nominal Frequency Supply Voltage Supply current Output Logic Type Load Output Levels Sym Fo Vcc Icc Output to Vcc-2V, or Thevenin Equivalent overall Symbol To Tst Vcc Ven/dis Conditions, Note Code A Code B Value -40 to +85 -50 to +90 -0.5 to 4.5 0 to Vcc MIN 150 3.135 2.375 TYP 3.3 2.5 80 LVPECL 50 MAX 500 3.465 2.625 100 Unit ºC ºC V V Unit MHz V mA Ohm V
Electrical Parameters
Voh Vol
Duty Cycle (Symmetry) Rise/Fall Time Jitter Integrated Tr/Tf J
Wavecrest characterized
At 50% of output voltage swing 20 to 80, 80 to 20 % Integrated from Phase Noise, 12 KHz to 20 MHz , RMS Random period, Accumul., pk-to-pk
Deterministic
Vcc1.025 Vcc1.620 45/55
50/50 0.35 0.2
55/45 0.4
% ns ps
2.5 2.5 25 3 6 -65 -95 -125 -140 -145 -148 See “Creating a Part Number” Not all combinations available, consult factory Vcc-1 0 Vcc Vcc-1.6
ps ps
Phase Noise
£(∆f)
Frequency Stability
∆F/F
@ 10 Hz @100 Hz @1 KHz @10KHz @100KHz @>1MHz Overall, including initial calibration, temperature, aging 10 years, shock and vibration PECL logic “1" PECL logic “0"
212.5 MHz
dBc/Hz
ppm
Enable Low Option Pin 2 Disabled Pin 2 Enabled
V
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
CRYSTAL CLOCK OSCILLATORS
Rev. AA-X29LXXX Series Continued LVPECL HF/UHF CLOCK (XO)
Electrical Connection Pin Connection 1 Enable/Disable or No Connect 2 N.C. 3 Gnd 4 Output 5 /Output 6 VCC Dimensions are typical in mm
7.5
NEL
2.0 0.5
1
2
3
1.37 5.20
1.37
6
2.540
5
4
Environmental and Mechanical Characteristics
Operating temp. range Mechanical Shock Thermal Shock Vibration Hermetic Seal Soldering conditions see part # table Per MIL-STD-202, Method 213, Cond. E Per MIL-STD-883, Method 1011, Cond. A Per MIL-STD-883, Method 2007, Cond. A Leak rate less than 1x10-8 atm.cc/s of helium See MAX reflow profile below
Maximum Reflow Profile
357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
