AA-A2D6HCH-FREQ

CRYSTAL CLOCK OSCILLATORS LVDS HF/UHF CLOCK (XO) Data Sheet 0631E Rev. - AA-A2D6XXX Series Description The AA-A2D6XXX Series of quartz crystal oscillators provide ultra high frequency with LVDS complementary outputs. The outputs can be disabled for test automation or combining multiple clocks. The device is based on low noise analog harmonic multiplication, and packaged in a miniature, low profile leadless FR4 based package with gold plated pads, which enhances compatibility with PCB material. Applications and Features • Wide frequency range – 150.0MHz to 500.000MHz • Fiber Channel; 10 GbE; Infiniband; Network Processors; SOHO Routing • High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions • Low Phase Noise, Low Jitter • Ultra High Frequency • Fast Rise and Fall times • Tight frequency stability - ±20 ppm overall available • RoHS Compliant, Lead Free Construction • Low cost Creating a Part Number AA - A 2D6 X X X - FREQ Package Code Overall Frequency Stability, ppm AA 6 pad 7.5x 5.2mm SMD E ±20 F ±25 Input Voltage G ±50 A 3.3V±5% H ±100 B 2.5V±5% 9 Customer specific Enable Option H Enable High N N/C Temperature Range, °C A 0 to 50 B 0 to 70 C -20 to 70 D -40 to 85 9 Customer specific 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS AA-A2D6XXX Series Continued LVDS HF/UHF CLOCK (XO) Data Sheet 0631E Rev. - Absolute Maximum Ratings Parameter Operating Temperature Range Storage Temperature Range Supply Voltage Enable/Disable Voltage Parameter Nominal Frequency Supply Voltage Supply current Load Output Levels Symb Fo Vcc Icc At receiving end between the outputs Differential amplitude Amplitude error Offset Voltage Offset Voltage error At outputs crossing, room temperature 20 to 80, 80 to 20 % Integrated from Phase Noise, 12 KHz to 20 MHz, RMS Random period, Accumul., pk-to-pk Deterministic 400 M 212.5 MHz @ 10 Hz @100 Hz @1 KHz @10KHz @100KHz @>1MHz Overall, including initial calibration, temperature, aging 10 years, shock and vibration CMOS logic 1 or N/C CMOS logic 0 90 247 1.125 45/55 Symbol To Tst Vcc Ven/dis Conditions, Note Code A Code B Value -40 to +85 -50 to +90 -0.5 to 4.5 0 to Vcc MIN 150 3.135 2.375 TYP 3.3 2.5 80 100 330 1.25 50/50 0.35 0.2 MAX 500 3.465 2.625 100 110 454 50 1.375 50 55/45 0.4 Unit ºC ºC V V Unit MHz V mA Ohm mV mV V mV % ns ps Electrical Parameters Vod Vof Duty Cycle (Symmetry) Rise/Fall Time Jitter Integrated Tr/Tf J Wavecrest characterized 2.5 2.5 25 3 6 -50 -45 -65 -95 -125 -140 -145 -148 See “Creating a Part Number” Not all combinations available, consult factory ps ps ps dBc dBc/Hz Subharmonics Phase Noise £(∆f) Frequency Stability ∆F/F ppm Enable High Option Pin 2 Enabled Pin 2 Disabled 0.7 Vcc 0 Vcc 0.3 Vcc V 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS Rev. AA-A2D6XXX Series Continued LVDS UHF CLOCK (XO) Electrical Connection Pin Connection 1 Enable/Disable or No Connect 2 N.C. 3 VEE /Ground 4 Output 5 /Output 6 VCC Dimensions are typical in mm 7.5 NEL 2.0 0.5 1 2 3 1.37 5.20 1.37 6 2.540 5 4 Environmental and Mechanical Characteristics Operating temp. range Mechanical Shock Thermal Shock Vibration Hermetic Seal Soldering conditions see part # table Per MIL-STD-202, Method 213, Cond. E Per MIL-STD-883, Method 1011, Cond. A Per MIL-STD-883, Method 2007, Cond. A Leak rate less than 1x10-8 atm.cc/s of helium See MAX reflow profile below Maximum Reflow Profile 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
