AA-AADY9F-FREQ

CRYSTAL OSCILLATORS Data Sheet 0637B Rev. B LVDS TCXO/TCVCXO AA-XADXXX Series Description The AA-XADXXX Series of quartz crystal oscillators provide excellent temperature stability with LVDS complementary outputs. The device is packaged in a miniature, low profile leadless FR4 based package with gold plated pads, which enhances compatibility with PCB material. Creating a Part Number AA - X AD X Package code AA – 6 pad 7.5x5x2 SMD X X -FREQ Temperature Stability, ppm E ±1 F ±2 G ±2.5 9 customer specific Operating Voltage A 3.3 V ± 5% B 2.5 V ± 5% TCXO/TCVCXO Option X No V. Control Y w/V. Control Temperature Range, ºC A 0 to 50 B 0 to 70 C -20 to 70 D -40 to 85 9 customer specific 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL OSCILLATORS Data Sheet 0637B Rev. B LVDS TCXO AA-XADXX Series Drawing Specification 7.5 Pin Connections: 1 – N/C or Vc 2 – N/C 3 – GND 4 – OUT 5 – Complementary OUT 6 – Vcc 0 .5 NEL 2.0 1 2 3 1.37 5.20 Dimensions are typical in mm 1.37 6 2.540 5 4 Absolute Maximum Ratings Parameter Operating Temperature Range Storage Temperature Range Supply Voltage Voltage Control Symbol To Tst Vcc Vc Value -40 to +85 -50 to +90 -0.5 to 4.5 0 to Vcc Unit ºC ºC V V 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL OSCILLATORS Data Sheet 0637B Rev. B LVDS TCXO AA-XADXX Series Electrical Parameters Parameter Nominal Frequency Supply Voltage Supply current Load Output Levels Symb Fo Vcc Icc Vod Vof Conditions, Note Code A Code B At receiving end between the outputs Differential amplitude Amplitude error Offset Voltage Offset voltage error At outputs crossing, room temperature 20 to 80, 80 to 20 % Integrated from Phase Noise, 12 KHz to 20 MHz , RMS Random period, Accumul. pk-to-pk Deterministic F>40MHz 40 M 20 MHz @ 10 Hz @100 Hz @1 KHz @10KHz @100KHz @>1MHz Over Temp -30 to 80 C See Aging, 1st year Aging 10 years Load Vcc Reflow Calibration as shipped 0.3V to 3.0V chart MIN 12.8 3.135 2.375 90 247 1.125 45/55 TYP 3.3 2.5 40 100 330 1.25 50/50 0.35 0.2 2.5 2.5 20 3 -50 -45 -85 -115 -135 -140 -145 -148 2.5 MAX 120 3.465 2.625 50 110 454 50 1.375 50 55/45 0.4 Unit MHz V mA Ohm mV mV V mV % ns ps ps ps Duty Cycle (Symmetry) Rise/Fall Time Jitter Integrated Wavecrest characterized Tr/Tf J 6 ps dBc dBc/Hz Sub-harmonics Phase Noise £(Δf) Frequency stability ΔF/F ppm 1 3.5 0.1 0.1/V 2 1 Pullability (Vc option) 5 ppm 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL OSCILLATORS Data Sheet 0637B Rev. B LVDS TCXO AA-XADXX Series Environmental and Mechanical Characteristics Operating temp. range Mechanical Shock Thermal Shock Vibration Hermetic Seal Soldering conditions see part # table Per MIL-STD-202, Method 213, Cond. A Per MIL-STD-883, Method 1011, Cond. A Per MIL-STD-883, Method 2007, Cond. A Leak rate less than 1x10-8 atm.cc/s of helium See MAX reflow profile below MAX Reflow Profile 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
