AA-XEXX

CRYSTAL CLOCK OSCILLATORS HCSL COMPATIBLE HF/UHF CLOCK (XO) Data Sheet 0631D Rev. A AA-XEXX Series Description The AA-XEXX Series of quartz crystal oscillators provide ultra high frequency with HCSL compatible complementary outputs. The device is based on low noise analog harmonic multiplication, and packaged in a miniature, low profile leadless FR-4 based package with gold plated pads, which enhances compatibility with PCB material. Applications and Features • Ultra High Frequency – up to 240.000MHz • Fiber Channel; 10 GbE; Infiniband; Network Processors; SONET/SDH • High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions • Low Phase Noise, Low Jitter • Fast Rise and Fall times • Tight frequency stability - ±20ppm overall available • RoHS Compliant, Lead Free Construction • Low cost Creating a Part Number AA - X E X X - FREQ Package Code Overall Frequency Stability, ppm AA 6 pad 7.5x5.2 SMD E ±20 F ±25 Input Voltage G ±50 A 3.3V±5% H ±100 B 2.5V±5% 9 Customer specific Temperature Range, °C A 0 to 50 B 0 to 70 C -20 to 70 D -40 to 85 9 Customer specific 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS AA-XEXX Series Continued HCSL Compatible HF/UHF Clock (XO) Data Sheet 0631D Rev. A Absolute Maximum Ratings Parameter Operating Temperature Range Storage Temperature Range Supply Voltage Enable/Disable Voltage Parameter Nominal Frequency Supply Voltage Supply current Logic Type Load Output Levels Duty Cycle (Symmetry) Rise/Fall Time Jitter Integrated Wavecrest characterized Symb Fo Vcc Icc Symbol To Tst Vcc Ven/dis Conditions, Note Code A Code B At receiving end each output, Rs=0 Ohm Output High 1,2 Output Low 1,2 Crossing Point At outputs crossing, room temperature From 0.175 to 0.525V Integrated from Phase Noise, 12 KHz to 20 MHz, RMS Random period, Accumul., pk-to-pk Deterministic @ 10 Hz @100 Hz @1 KHz @10KHz @100KHz @>1MHz Overall, including initial calibration, temperature, aging 10 years, shock and vibration @ Vc=Vcc/2; APR 50ppm, or less Value -40 to +85 -50 to +90 -0.5 to 4.5 0 to Vcc MAX 240 3.135 3.3 3.465 2.375 2.5 2.625 80 100 HCSL Compatible 50 660 250 45/55 700 0 350 50/50 0.35 0.2 2.5 2.5 25 3 6 -45 -35 -65 -95 -125 -140 -145 -148 See “Creating a Part Number” Not all combinations available, consult factory 850 550 55/45 0.5 MIN TYP Unit ºC ºC V V Unit MHz V mA Ohm mV V mV % ns ps ps ps ps dBc dBc/Hz Electrical Parameters Voh Vol Vcr Tr/Tf J Sub-harmonics Phase Noise £(∆f) Frequency Stability, usually not specified unless necessary, APR is specified to incorporate stability ∆F/F ppm 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS AA-XEXX Series Continued HCSL Compatible HF/UHF Clock (XO) 7.5 Rev. A Electrical Connection Pin Connection 1 Enable/Disable or No Connect 2 N/C 3 Gnd 4 Output 5 /Output 6 VCC Dimensions are typical in mm NEL 2.0 0.5 1 2 3 1.37 5.20 1.37 6 2.540 5 4 Environmental and Mechanical Characteristics Operating temp. range Mechanical Shock Thermal Shock Vibration Hermetic Seal Soldering conditions see part # table Per MIL-STD-202, Method 213, Cond. E Per MIL-STD-883, Method 1011, Cond. A Per MIL-STD-883, Method 2007, Cond. A Leak rate less than 1x10-8 atm.cc/s of helium See MAX reflow profile below Maximum Reflow Profile 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
