HA-A1440-FREQ

CRYSTAL CLOCK OSCILLATORS CMOS Data Sheet 0014A Rev. J HA-A1440 Series Description The HA-A1440 Series of quartz crystal oscillators provide enable/disable 3-state CMOS compatible signals for bus connected systems. Supplying Pin 1 of the HA-A1440 units with a logic “1" or open enables its pin 5 output. In the disabled mode, pin 5 presents a high impedance to the load. Features • Wide frequency range– 70.1MHz to 125.0MHz • User specified tolerance available • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 1000g • All metal, resistance weld, hermetically sealed package • 3.3 Volt operation Electrical Connection Pin 1 4 5 8 Connection Enable Input Grd & Case Output VDD • Low Jitter • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • Low power consumption • Gold plated leads - Solder dipped leads available upon request • RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied) Dimensions are in inches and (MM) 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HA-A1440 Series CMOS Continued Data Sheet 0014A Rev. J Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Tpz Jitter, RMS(2) Frequency Stability (1) Symbol Conditions ------------@ VDD /2 VOL @ 600µA VOH @ 600µA tr,tf 10-90% ----------------dF/F Overall conditions including: voltage, calibration, temp., 10 yr aging, shock, vibration Min 70.1MHz 45/55% ----VDD-0.2V -------------100ppm Typical --------0.1V VCD-0.1V 1 ns ------------Max 125.0MHz 55/45% 0.2V ----2 ns 100 ns 5 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Lead temperature Load Start-up time Symbol VDD IDD IO TA TS PD TL ---tS Conditions ----No Load ----------------Soldering, 10 sec. --------Min 3.135V 0.0 mA 0.0 mA 0°C -55°C ----------------Typical 3.3V 40mA ------------------------2 ms Max 3.465V 60mA ±25.0 mA 70°C 125°C 208 mW 300°C 15pf 10 ms Environmental and Mechanical Characteristics Mechanical Shock Per MIL-STD-202, Method 213, Condition E Thermal Shock Per MIL-STD-833, Method 1011, Condition A Vibration 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz Soldering Condition 300°C for 10 seconds Hermetic Seal Leak rate less than 1 x 10 -8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) Jitter performance is frequency dependent. Please contact factory for full characterization. RMS jitter bandwidth of 12kHz to 20MHz. Test Load: Creating a Part Number HA - A144X - FREQ Package Code HA Leaded 4 pin (8 pin) SA Leaded 4 pin (8 pin) SMD Gull Wing Input Voltage Code Specification A 3.3V 5V Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
