HS-460

CRYSTAL CLOCK OSCILLATORS CMOS (TTL Compatible) Data Sheet 0021E Rev. F HS-460 Series Description The HS-460 Series of quartz crystal oscillators are resistance welded in an all metal package, offering RFI shielding, and are designed to survive standard wave soldering operations without damage. Insulated standoffs to enhance board cleaning are standard. Features • Wide frequency range–0.5MHz to 30.0MHz • User specified tolerance available • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • All metal, resistance weld, hermetically sealed package • Low Jitter Electrical Connection Pin 1 7 8 14 Connection N.C. Grd & Case Output VDD • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • High frequencies due to proprietary design • Gold plated leads - Solder dipped leads available upon request • CMOS and TTL output levels • RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied) 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HS-460 Series Continued CMOS (TTL Compatible) Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Jitter, RMS(2) Frequency Stability (1) Symbol --------VOL VOH tr,tf ----dF/F Conditions ----@ VDD/2 @ 600µA @ 16mA @ 600µA @ 16mA 10-90%VO ----Overall conditions including: voltage, calibration, temp., 10 yr aging, shock, vibration Min 0.5MHz 45/55% --------VDD-0.2V VDD-0.4V ---------100ppm Data Sheet 0021E Rev. F Typical ------------------------------------- Max 30.0MHz 55/45% 0.2V 0.4V --------3 ns 8 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Lead temperature Load Start-up Time Symbol VDD IDD IO TA TS PD TL ----ts Conditions ----No Load ----------------Soldering, 10 sec. ----
