HS-A142C-FREQ

CRYSTAL CLOCK OSCILLATORS CMOS Data Sheet 9617F Rev. P HS-A1420 Series Description The HS-A1420 Series of quartz crystal oscillators provide enable/disable 3-state CMOS compatible signals for bus connected systems. Supplying Pin 1 of the HS-A1420 units with a logic “1" or open enables its output. In the disabled mode, output pin presents a high impedance to the load. All units are resistance welded in an all metal package, offering RFI shielding, and are designed to survive standard wave soldering operations without damage. Insulated standoffs to enhance board cleaning are standard. Features • Wide frequency range– 40.1MHz to 70.0MHz • User specified tolerance available • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • All metal, resistance weld, hermetically sealed package • 3.3 Volt operation Electrical Connection Pin 1 7 8 14 Connection Enable Input Grd & Case Output VDD • Low Jitter • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • Low power consumption • Gold plated leads - Solder dipped leads available upon request • RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied) Dimensions are in inches and (MM) 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HS-A1420 Series CMOS Continued Data Sheet 9617F Rev. P Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Tpz Enable/Disable Logic High Voltage Enable/Disable Logic Low Voltage Jitter, RMS(2) Frequency Stability (1) Symbol --------VOL VOH tr,tf ----------------dF/F Conditions ----@ VDD /2 @ 600µA @ 600µA 10-90% ----------------Overall conditions including: voltage, calibration, temp., 10 yr aging, shock, vibration Min 40.1MHz 45/55% ----VDD-0.2V --------2.0V ---------100ppm Typical ----------------------------------------Max 70.0MHz 55/45% 0.2V ----8 ns 25 ns ----0.8V 5 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Lead temperature Load Start-up time Symbol VDD IDD IO TA TS PD TL ---tS Conditions ----No Load ----------------Soldering, 10 sec. --------Min 3.135V 0.0 mA 0.0 mA 0°C -55°C ----------------Typical 3.3V ----------------------------2 ms Max 3.465V 40mA ±16.0 mA 70°C 125°C 138 mW 300°C 15pf 10 ms Environmental and Mechanical Characteristics Mechanical Shock Thermal Shock Vibration Soldering Condition Hermetic Seal Per MIL-STD-202, Method 213, Condition E Per MIL-STD-833, Method 1011, Condition A 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz 300°C for 10 seconds Leak rate less than 1 x 10 -8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) Jitter performance is frequency dependent. Please contact factory for full characterization. RMS jitter bandwidth of 12kHz to 20MHz. Test Load: Creating a Part Number HS - A142X - FREQ Package Code HS Leaded 4 pin (14 pin) SM Leaded 4 pin (14 pin) SMD Gull Wing Input Voltage Code Specification A 3.3V 5V Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
