OH-A8FVP28D

CRYSTAL OSCILLATORS OH-X8FXXXXX Series HF/UHF OCXO Low Power SMD Description: OH-X8FXXXXX Series of Oven Controlled Crystal Oscillators (OCXO) provides High and Ultra High Frequency with SC-cut stability performance, extremely low phase noise and power consumption, with variety of different output types in a miniature SMD package 1.0 (25,4 mm) 1 Data Sheet 0635C Rev. A 5 Features • • • • • • Very Low Power Consumption Very Low Phase Noise Excellent SC-cut Frequency Stability Ultra High Frequency – up to 1 GHz CMOS, Sine-Wave, PECL, LVDS outputs available Stratum3E available 2 0.87 (22,0 mm) 3 4 0.5 (12.72 mm) 0.1 (2,5 mm) 3 4 5 0.70 (17,8 mm) 2 6 0.2 (5 mm) 1 7 0.1 (2,5 mm) Creating a Part Number OH - X 8F X X XX X Package Code OH 7 pad 25x22mm SMD Supply Voltage Code 0 A Specification 5V ±5% 3.3V ±5% Temperature Range Code A B C D E F Specification 0°C to 50°C -10°C to 60°C 0°C to 70°C -20°C to 70°C -30°C to 70°C -40°C to 80°C OCXO/OCVCXO Option Code X V Specification No V. Control W/ V. Control Output Type Code C S L P Specification CMOS Sine-wave LVDS PECL Temperature Stability Code 17 58 28 18 YZ Specification 1x10-7 5x10-8 2x10-8 1x10-8 Yx10-Z 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL OSCILLATORS OH-X8FXXXXX Series HF/UHF OCXO Low Power SMD Specifications Parameter Symb Input Break Down Voltage Storage temp. Contr. Voltage Vcc Ts Vc F CMOS Sine-wave PECL, LVDS Condition Min Typ Max Unit Note Data Sheet 0635C Rev. A Absolute Maximum Ratings -0.5 -40 -1 30 30 30 3.135 4.75 5.5 85 9 200 1,000 1,000 3.465 5.25 90 160 V °C V MHz Electrical Frequency Range Input Voltage Input Current Frequency Stability Vcc Icc ΔF/F At room, steady state vs. Temperature vs. Vcc aging As shipped, 25ºC CMOS Sine PECL LVDS @50% 20 to 80 % CMOS CMOS PECL PECL Differential amplitude Amplitude error Offset voltage Offset error Sinewave Into 50 Ohm 1σ Sine, PECL, LVDS CMOS, Sine Sine-wave @10 Hz @100 Hz @1 KHz @10 KHz @100 KHz @10 Hz @100 Hz @1 KHz @10 KHz @100 KHz 3.30 5.0 V mA Calibration Load ΔF/F Duty cycle Rise/Fall time Logic "1" level Logic "0" level Logic "1" level Logic "0" level Output Levels, LVDS Tr/Tf Voh Vol Voh Vol Vo d Vo f ±50 ppb ±2 ppb/V ±0.1 ppm/year ±0.5 ppm ±0.1 ppm 15pF/10KOhm Internally AC-coupled 50 Ohm 50 Ohm to Vcc-2V or Thevenin equivalent 100 Ohm between the outputs, receiving end 45 50 55 % 3 ns 0.35 0.9Vcc V 0.1Vcc V Vcc-0.96 Vcc-0.81 V Vcc-1.85 Vcc-1.65 V 247 330 454 mV 50 1.375 50 0 4 3 7 2 0.4 0.2 -45 mV V mV dBm ms ps dBc dBc dBc dBc/Hz 3 5 @ 100 MHz, 3.3V @ 622 MHz, 3.3V See chart First Year 15 years CMOS, PECL, LVDS CMOS PECL, LVDS 100K available 100K available 1.125 1.25 Output power Start up time Phase jitter Subharmonics Spurious Harmonics SSB Phase Noise P Ts 3.3V 5.0V 100 Hz to 20 MHz 12 KHz to 20 MHz F>250MHz F< 250 MHz SSB Phase Noise Input Impedance Control voltage Modulation bandwidth Deviation -30 -100 -125 -140 -160 -165 -80 -100 -120 -145/-140 -150/-145 > 10KOhm 0 100 Hz 10 1 0.4 -40 none -60 -25 @100 MHz, CMOS, Sine dBc/Hz @622 MHz; Sine/PECL,LVDS Vc MB 3.3 V Contact Factory for wider MB Vc=0V to 3.3V,25°C ±0.5 ±1.0 ppm 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL OSCILLATORS OH-X8FXXXXX Series HF/UHF OCXO Low Power SMD Rev. A Data Sheet 0635C Environmental and Mechanical 0°C to 70°C , -40°C to 85°C, see chart, page 1 Operating temp. range Per MIL-STD-202, Method 213, Cond. E Mechanical Shock Per MIL-STD-883, Method 1011, Cond. A Thermal Shock Per MIL-STD-883, Method 2007, Cond. A Vibration 260°C for 10 s leads only Soldering Conditions Hermetic Seal Leak rate less than 5x10-8 atm.cc/s of helium Electrical Connections Pin Out Pin #1- Voltage Control ; Pin #2 – N/C ; Pin #3 – Vcc; Pin#4 – Output, CMOS or Sine; Pin#5 – PECL/LVDS Output; Pin#6 – PECL/LVDS Complementary Out; Pin #7 – GND Maximum solder reflow profile SMD Reflow Profile 250 Temperature, °C 200 150 100 50 0 0 50 100 150 200 Time, s 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
