PJ-0A20F-FREQ

PJ-0A20X Series compatible signals. CMOS TCXO PJ-0A20X Series Rev C Frequency Range: 10.0 MHz to 52.0 MHz Description The PJ-0A20X Series of temperature compensated quartz crystal oscillators provide CMOS Features Size, mm 9 x 14 I/O 6J Lead Supply Voltage 5.0 V / 3.3 V • Frequency range–10.0MHz to 52.0MHz • User specified tolerance • Will withstand SMD reflow temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • Metal lid electrically connected to ground to reduce EMI • Double Sealed Case • High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions • Low Jitter - Wavecrest jitter characterization available • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • Low power consumption • Gold plated leads • RoHS Compliant, Lead Free Construction Creating a Part Number Package Code PJ 6 J Lead 9x14 mm SMD Input Voltage Code Specification 0 5.0 V A 3.3 V PJ-0A2XX-FREQ Performance 9 Customer Specific D ±10 ppm -40°C to 85oC E ±2.5 ppm -40°C to 85oC F ±1 ppm 0°C to 70oC Trim Adjustment 0 Pin1=NC 1 Pin1=VCT Drawing Specifications Electrical Connections Pad Connection 1 VCT or NC 2 NC 3 Ground 4 Output 5 NC 6 VCC For the most up to date specifications on each NEL product, log on to our website—www.nelfc.com Dimension shown in inches and (mm). 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone: 262-763-3591 Fax: 262-763-2881 Email: nelsales@nelfc.com www.nelfc.com I3 CMOS TCXO PJ-0A20X Series Rev C Frequency Range: 10.0 MHz to 52.0 MHz Operating Conditions and Output Characteristics Electrical Characteristics Parameter Symbol — — VOL VOH tr, tf — dF/F — — Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Jitter RMS(1) Frequency Stability(3) Aging Trim Range(4) — @ VDD/2 @ 600µA @ 600µA 10-90% — Overall conditions including: voltage, calibration, temp., shock, vibration — VCT=0 to 5.0 Volts Conditions 10.000 MHz 45/55% — VDD-0.2V — — -2.5 ppm — -3 ppm Min Typical — — — — — — — — — 52.000 MHz 55/45% 0.2V — 2 ns 3 psec +2.5 ppm ±1 ppm/yr +3 ppm Max Supply Voltage(2) Supply Current Output Current Operating Temperature Storage Temperature Power Dissipation Lead Temperature Load Start-up Time Mechanical Shock Thermal Shock Vibration Soldering Condition Hermetic Seal General Characteristics Parameter Symbol VDD IDD IO TA TS PD TL — tS 5V ±5% No Load — — — — Soldering, 10 sec. — — Conditions 4.75 V 0.0 mA 0.0 mA -40ºC -55ºC — — — — Min Typical 5.0 V 4mA — — — — — — — 5.25 V 8 mA ±25.0 mA 85ºC 125ºC 42 mW 300ºC 15 pf 20 ms Max Environmental and Mechanical Characteristics Per MIL-STD-202, Method 213, Condition E Per MIL-STD-833, Method 1011, Condition A 0.060” double amplitude 10 Hz to 55 Hz, 35g’s 55 Hz to 2000 Hz 300ºC for 10 seconds Leak rate less than 1 x 10-8 atm.cc/sec of helium Footnotes: 1) Jitter performance is frequency dependent. Please contact factory for full Wavecrest characterization. RMS jitter bandwith of 12kHz to 20MHz. 2) Internal high frequency power source decoupling. 3) Contact factory for other available frequency stability tolerances. 4) Optional trim adjustment. Test Load I4
