PJ-A2981-FREQ

CRYSTAL CLOCK OSCILLATORS Data Sheet 0208E Rev. J LVDS PJ-A2D00 Series Description The PJ-A2D00 Series of quartz crystal oscillators provide LVDS compatible signals in a ceramic SMD package. Systems designers may now specify space-saving, cost-effective packaged LVDS oscillators to meet their timing requirements. Features • Wide frequency range–80.0MHz to 312.5MHz • User specified tolerance available • Space-saving alternative to discrete component oscillators • High shock resistance, to 1000g • 3.3 volt operation (other voltages available upon request) • Metal lid electrically connected to ground to reduce EMI • Enable/Disable • LVDS output on pin 4, complement on Pin 5 • Low Jitter - Wavecrest jitter characterization available • High Reliability - NEL HALT/HASS qualified for crystal oscillator start-up conditions • Overtone technology • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • High frequencies due to proprietary design • Gold plated leads • RoHS Compliant, Lead Free Construction Electrical Connection Pin 1 2 3 4 5 6 Connection Enable/Disable N.C. Ground Output Output Complement VCC 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS PJ-A2D00 Series LVDS Continued Data Sheet 0208E Rev. J Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle(2) Logic 0 (2) Logic 1 (2) Differential Voltage (2) Disable Voltage Enable Voltage(5) Rise & Fall Time (2) Tpd (4) Jitter, RMS(3) Frequency Stability (1) Symbol Conditions ------------@ VO /2 VOL ----VOH ----VOD --------VEE=0V ----VEE=0V tr,tf 20-80%VO ----------------dF/F Overall conditions including: voltage, calibration, temp., 10 yr aging, shock, vibration Min 80.0MHz 45/55% 0.80V 1.25V 250 mV ----2.0V -----0.5 ns -----100ppm Typical ----------------------------0.8 ns ------------Max 312.5MHz 55/45% 1.10V 1.55V 450 mV 0.8V ----1.0 ns +0.5 ns 3 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Solder temperature Load Start-up time Symbol Conditions ----VCC ICC ----Continuous Output Current IO TA ---------TS ----PD TL 4 minutes 100 ohms across differential outputs tS ----Min 3.135V 0.0 mA 0.0 mA 0°C -55°C ------------Typical 3.3V ------------------------2 ms Max 3.465V 80 mA ±50.0 mA 70°C 125°C 277 mW 253°C 10 ms Environmental and Mechanical Characteristics Mechanical Shock Thermal Shock Vibration Hermetic Seal Per MIL-STD-202, Method 213, Condition E Per MIL-STD-883, Method 1011, Condition A 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz Leak rate less than 1 x 10 -8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) With Load of 100 ohms across differential outputs. 3) Jitter performance is frequency dependent. Please contact factory for full Wavecrest characterization. RMS jitter bandwidth of 12kHz to 20MHz. 4) Tpd is phase shift between the falling edge of pin 4 and the rising edge of pin 5. 5) Open to enable pin also enables the output Creating a Part Number PJ - A2D0X - FREQ Package Code PJ 6 J Lead SMD Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C Input Voltage Code Specification A 3.3V B 2. 5V 5V 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
