SJ-160

CRYSTAL CLOCK OSCILLATORS TTL Data Sheet 0012K Rev. H SJ-160 Series Description The SJ-160 Series of quartz crystal oscillators are designed to survive standard wave soldering operations without damage. Features • Wide frequency range–2.25MHz to 85.0MHz • User specified tolerance available • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • Metal lid electrically connected to ground to reduce EMI Electrical Connection Pin 1 2 3 4 Connection N.C. Grd & Case Output VCC • Low Jitter • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • High frequencies due to proprietary design • Gold plated leads • Low power consumption • RoHS Compliant, Lead Free Construction 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS SJ-160 Series TTL Continued Data Sheet 0012K Rev. H Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Jitter, RMS(2) Frequency Stability (1) Symbol --------VOL VOH tr,tf ----dF/F Conditions ----@ VCC/2 @ 16mA @ 0.4mA @ 0.4 to 2.4V
