CRYSTAL CLOCK OSCILLATORS Differential Positive ECL (DPECL) Data Sheet 9318A Rev. N HK-2910 Series Description The HK-2910 Series of quartz crystal oscillators provide DPECL Fast Edge compatible signals. This device is to operate using positive voltage and uses multiple ground pins for improved signal integrity. This device is intended to operate on positive voltage for PECL applications. Features • Wide frequency range–122.0MHz to 300.0MHz • User specified tolerance available • Case at electrical ground • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • All metal, resistance weld, hermetically sealed package • High shock resistance, to 1500g • Low Jitter • Overtone technology • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • Dual ground plane for added stability • No internal PLL avoids cascading PLL problems • High frequencies due to proprietary design • RoHS Compliant, Lead Free Construction Electrical Connection Pin 1 2 6 7 8 9 13 14 Connection VCC VEE Case VEE Case Output /Output VEE Case VEE Case Enable/Disable All dimensions expressed in Inches/MM 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HK-2910 Series Continued Differential Positive ECL (DPECL) Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 (2) Logic 1(2) Rise & Fall Time Jitter, RMS(3) Enable Voltage(4) Disable Voltage Frequency Stability (1) Symbol Conditions Min --------122.0MHz ----@ 50% points 45/55% VOL ----VCC-1.95V VOH ----VCC-1.02V tr,tf 20-80%VO with 50 ohm load to VCC-2V -------------------with VEE=0V 0V 3.0V ----with VEE=0V dF/F Overall conditions including: -100ppm voltage, calibration, temp., 10 yr aging, shock, vibration Data Sheet 9318A Rev. N Typical ----------------350 psec ----------------- Max 300.0MHz 55/45% VCC-1.60V VCC-0.74V 600 psec 5 psec 1.0V VCC +100ppm General Characteristics Parameter Supply Voltage Supply Current Symbol VCC ICC Conditions ----50 ohm termination To 2.00V below VCC Low level Output Current ---------Min 4.75V 0.0 mA Typical 5.0V --------------------2 ms Max 5.25V 120 mA ±50.0 mA 70°C 125°C 300°C 10 ms Output current IO 0.0 mA 0°C Operating temperature TA -55°C Storage temperature TS Input: Logic High (ECL) - Disables VEE or Open - Enables Soldering, 10 sec. ----Lead temperature TL Load 50 Ohm to VCC-2V or Thevenin Equivalent, Bias Required --------Start-up time tS Environmental and Mechanical Characteristics Mechanical Shock Thermal Shock Vibration Soldering Condition Hermetic Seal Per MIL-STD-202, Method 213, Condition E Per MIL-STD-833, Method 1011, Condition A 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz 300°C for 10 seconds Leak rate less than 1 x 10 -8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) VOL, VOH, referenced to ground 3) Jitter performance is frequency dependent. Please contact factory for full characterization. RMS jitter bandwidth of 12kHz to 20MHz. 4) Open to Enable pin also enables to output. Creating a Part Number HK - A291X - FREQ Package Code HK Leaded 8 pin (14pin) SK 8 pin (14 pin) SMD Gull Wing Input Voltage Code Specification A 3.3V 5V Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
