SM-A145A-FREQ

CRYSTAL CLOCK OSCILLATORS CMOS Data Sheet 0012U Rev. F HS-A1450 Series Description The HS-A1450 Series of quartz crystal oscillators provide enable/disable 3-state CMOS compatible signals for bus connected systems. Supplying Pin 1 of the HS-A1450 units with a logic “1" or open enables its pin 8 output. In the disabled mode, pin 8 presents a high impedance to the load. All units are designed to survive wave soldering operations without damage. Features • Wide frequency range– 4.0MHz to 40.0MHz • User specified tolerance available • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • All metal, resistance weld, hermetically sealed package • 3.3 Volt operation Electrical Connection Pin 1 7 8 14 Connection Enable Input Grd & Case Output VDD • Low Jitter • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • Low power consumption • Gold plated leads - Solder dipped leads available upon request • TTL compatible (HCT) at specified supply voltage • RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied) Dimensions are in inches and (MM) 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HS-A1450 Series CMOS Continued Data Sheet 0012U Rev. F Operating Conditions and Output Characteristics Electrical Characteristics Parameter Frequency Duty Cycle Logic 0 Logic 1 Rise & Fall Time Tpz Jitter, RMS(2) Frequency Stability (1) Symbol Conditions ------------@ VDD /2 VOL @ 600µA VOH @ 600µA tr,tf 10-90% ----------------dF/F Overall conditions including: voltage, calibration, temp., 10 yr aging, shock, vibration Min 4.0MHz 45/55% ----VDD-0.2V -------------100ppm Typical --------------------------------Max 40.0MHz 55/45% 0.2V ----3 ns 25 ns 8 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Lead temperature Load Start-up time Symbol VDD IDD IO TA TS PD TL ---tS Conditions ----No Load ----------------Soldering, 10 sec. --------Min 3.135V 0.0 mA 0.0 mA 0°C -55°C ----------------Typical 3.3V ----------------------------2 ms Max 3.465V 30mA ±16.0 mA 70°C 125°C 104 mW 300°C 15pf 10 ms Environmental and Mechanical Characteristics Mechanical Shock Per MIL-STD-202, Method 213, Condition E Thermal Shock Per MIL-STD-833, Method 1011, Condition A Vibration 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz Soldering Condition 300°C for 10 seconds Hermetic Seal Leak rate less than 1 x 10 -8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) Jitter performance is frequency dependent. Please contact factory for full characterization. RMS jitter bandwidth of 12kHz to 20MHz. Test Load: Creating a Part Number HS - A145X - FREQ Package Code HS Leaded 4 pin (14 pin) SM Leaded 4 pin (14 pin) SMD Gull Wing Input Voltage Code Specification A 3.3V 5V Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
