CRYSTAL CLOCK OSCILLATORS Data Sheet 9826B Rev. G HS-169 Single Frequency Oscillator 53.125MHz Description The HS-169 crystal oscillator is designed to support the TachyonTM clocking requirements at 53.125MHz. Features • Meets HP TACHYONTM Clock Generator • Will withstand vapor phase temperatures of 253°C for 4 minutes maximum • Space-saving alternative to discrete component oscillators • High shock resistance, to 3000g • All metal, resistance weld, hermetically sealed package • Low Jitter Electrical Connection Pin 1 7 8 14 Connection N.C. Grd & Case Output VCC • High Q Crystal actively tuned oscillator circuit • Power supply decoupling internal • No internal PLL avoids cascading PLL problems • Gold plated leads - Solder dipped leads available upon request • Low power consumption • RoHS Compliant, Lead Free Construction (unless solder dipped leads are supplied) 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com CRYSTAL CLOCK OSCILLATORS HS-169 Continued Single Frequency Oscillator 53.125MHz Operating Conditions and Output Characteristics Electrical Characteristics Parameter Duty Cycle Logic 0 Logic 1 Rise & Fall Time Jitter, RMS(2) Frequency Stability (1) Symbol Conditions ----@ VCC/2 VOL @ 16mA VOH @ 0.4mA tr,tf @ 0.4 to 2.4V --------dF/F Overall conditions including: voltage, calibration, temp., 20 yr aging, shock, vibration Min 45/55% ----2.4V ---------100ppm Data Sheet 9826B Rev. G Typical ----0.3V 4.0V ------------- Max 55/45% 0.4V ----2.8 ns 5 psec +100ppm General Characteristics Parameter Supply Voltage Supply Current Output current Operating temperature Storage temperature Power Dissipation Lead temperature Load Start-up Time Symbol VCC ICC IO TA TS PD TL ----ts Conditions ----No Load ----------------Soldering, 10 sec. --------Min 4.75V 0.0 mA 0.0 mA 0°C -55°C ----------------Typical 5.0V --------------------------------Max 5.25V 60 mA ±25.0 mA 70°C 125°C 315 mW 300°C 10 TTL gate 3 ms Environmental and Mechanical Characteristics Mechanical Shock Thermal Shock Vibration Soldering Condition Hermetic Seal Per MIL-STD-202, Method 213, Condition E Per MIL-STD-833, Method 1011, Condition A 0.060" double amplitude 10 Hz to 55 Hz, 35g’s 55Hz to 2000 Hz 300°C for 10 seconds Leak rate less than 1 x 10-8 atm.cc/sec of helium Footnotes: 1) Standard frequency stability (±20,±25,±50ppm & others available) 2) Jitter performance is frequency dependent. Please contact factory for full characterization. RMS jitter bandwidth of 12kHz to 20MHz. Test Load: Creating a Part Number HS - X16X - FREQ Package Code HS Leaded 4 pin (14 pin) SM Leaded 4 pin (14 pin) SMD Gull Wing Input Voltage Code Specification A 3.3V 5V Tolerance/Performance 0 ±100ppm 0-70°C 1 ±50ppm 0-70°C 7 ±25ppm 0-70°C 9 Customer Specific A ±20ppm 0-70°C B ±50ppm -40 to +85°C C ±100ppm -40 to +85°C 357 Beloit Street, P.O. Box 457, Burlington, WI 53105-0457 U.S.A. Phone 262/763-3591 FAX 262/763-2881 Email: nelsales@nelfc.com www.nelfc.com
