SC-2345

Portable, Shielded SCC Module Carriers NI SC-2345 Series, NI SC-2350 • Accept up to 20 SCC modules • Portable, low-profile packaging • Cable directly to an E Series or Basic multifunction device • Powered by DAQ device (additional power options available) Operating Systems • Windows 2000/NT/XP Recommended Software • LabVIEW ™ • LabWindows™/CVI™ • Measurement Studio™ • Lookout • VI Logger SC-2345 Connector Block • Screw terminal connectivity SC-2345 with Configurable Connectors • Panelettes for sensor connectivity, control, and display • Blank panelettes for filler Other Compatible Software • Visual Basic • C/C++, C# Measurement Services Software • NI-DAQ 7 SC-2350 with Configurable TEDS Connectors • Accepts up to 16 channels of TEDS Class II smart sensors • Panelettes for sensor connectivity Overview The National Instruments SC-2345 Series consists of two types of carriers, the NI SC-2345 connector block and the SC-2345 with configurable connectors. The SC-2350 is a similar carrier with configurable TEDS (Transducer Electronic Data Sheet) connectors for connecting to smart TEDS sensors. These enclosures for SCC signal conditioning modules connect directly to 68-pin DAQ devices. They include sockets for SCC modules, along with screw terminals for convenient connection to digital I/O and counter/time (GPCTR) signals from the DAQ device. These carriers offer three power options to increase the flexibility of deployment. Sockets J17 through J20 access the two analog output channels and the GPCTR channels 0 and 1. SC-2345 Connector Block The SC-2345 includes 20 SCC sockets, labeled J1 through J20 (see Figure 1). Sockets J1 through J8 accommodate SCC modules for conditioning signals on the analog input channels of the DAQ device. For example, an SCC module plugged into socket J1 conditions signals for channels 0 and 8 of the device. You can use sockets J9 through J16 for either digital I/O modules or dual-stage analog input conditioning. When using dual-stage conditioning of analog inputs (for applicable modules only in the SC-2345 series carriers), wire your input signal to the first-stage module (in sockets J9 through J16). The SC-2345 routes the output signal of the first-stage SCC module to the input of the second stage SCC module internally (see Figure 2). When using sockets J9 through J16 for digital I/O, simply plug in a digital SCC module or the SCC-FT01 for custom digital applications. You can use any combination of SCC digital input or digital output modules. The digital I/O lines of E Series or Basic multifunction DAQ devices are configurable for input and output on a line-by-line basis. You can also access the DIO lines of the DAQ device using the screw terminal block. Figure 1. Diagram of Socket Layouts on SC-2345 Connector Block Analog SCC Connected to J1 Inputs Second Stage Analog SCC Connected to J1 First Stage Analog SCC Connected to J9 Inputs Signals routed to the second stage SCC internally A. Single-Stage Analog Input SCC Configuration B. Dual-Stage Analog Input SCC Configuration Figure 2. Single-Stage and Dual-Stage Analog Input SCC Configuration for the SC-2345 Connector Block Portable, Shielded SCC Module Carriers SC-2345 Carrier with Configurable Connectors The SC-2345 with Configurable Connectors is electrically and functionally identical to the SC-2345 connector block. The only differences are the orientation of some modules and the addition of I/O connector and interface panelettes. This carrier is available with either a side 68-pin connector (recommended for DAQCard products) or a rear 68-pin connector (recommended for DAQPad products). The SC-2345 with Configurable Connectors handles dual-stage conditioning and digital I/O modules. It also offers custom connectivity by adding panelettes along its front and rear panels. Select up to 18 panelettes for side-mount 68-pin versions, or 15 panelettes for rear-mount 68-pin versions. With I/O panelettes, you can connect your sensor directly to the SCC system. With interface panelettes, you can add hardware controls and displays to your system. Blank panelettes are also available to fill unused positions or for modification to fit your custom application needs. The SC-2350 contains a TEDS microcontroller with two digital lines per analog input channel for communication with Class II smart TEDS sensors (for more information on smart TEDS sensors refer to ni.com/sensors). Sensors Plug&Play™ The IEEE 1451.4 standard delivers plug-and-play capability to analog sensors. End users, systems integrators, and developers can automate the configuation of measurement systems for analog sensors. By defining an easy add-on approach that brings TEDS benefits to all types of sensors, the standard makes data acquisition systems easier to set up, configure, and maintain. The TEDS structure is compact and flexible enough to handle a very wide range of sensor requirements. Smart TEDS Sensors An IEEE 1451.4 smart TEDS sensor consists of the analog components and an embedded memory chip, which together provide the mixed-mode interface for analog and digital signals. A smart TEDS sensor identifies and describes itself – providing the manufacturer, sensor model number, serial number, measurement range, sensitivity, and calibration information. TEDS information resides on a memory chip (EEPROM) within the sensor and is accessed by measurement systems such as the SC-2350 via a simple low-cost serial interface. SC-2350 The SC-2350 includes 10 SCC module sockets, labeled J1 through J8, J17, and J18 (see Figure 3). Sockets J1 through J8 accommodate SCC modules for conditioning signals on the analog input channels of the DAQ device. For example, an SCC module plugged into socket J1 would condition signals for channels 0 and 8 of the device. You can use sockets J17 and J18 for SCC modules that condition analog signals on the output channels of the DAQ device. Figure 3. Diagram of Socket Layout for SC-2350 1SCC 2 SCC 3 SCC Socket Reference Designator Socket Key Slot Test Header 5 Serial Number Number Block 9 Power 10 J25 11 J21 LEDs 6 Assembly 7 Screw-Terminal 8 J24 4 50-Pin 2 National Instruments • Tel: (800) 433-3488 • Fax: (512) 683-9300 • info@ni.com • ni.com Portable, Shielded SCC Module Carriers Panelette Minithermocouple jack Thermocouple jack BNC SMB Banana jack LEMO (B-Series) MIL-Spec 9-pin D-Sub Description J or K-type or uncompensated J or K-type or uncompensated BNC connector SMB connector Banana jack 2-pin female 4, 6-pin female 2, 4, 6-pin female Single (male) Single (female) Dual (male) Dual (female) On – off (On – off – on) (On – off – on) Red, green, yellow, and orange LEDs 1 turn, 10 Ω Small Filler panel Connectors/Units per Panelette 2 2 1 1 2 4 2 2 1 1 1 1 2 2 2 2 1 4 1 1 – Slot Width 1 1 1 1 1 1 1 1 1 1 2 2 3 3 1 1 1 1 1 2 – Accessories The SC-2345 with configurable connectors and SC-2350 offer two optional accessories. For 19 in. rack systems, choose the rack-mount kit. If you are using two SCC systems, or a single SCC system with a DAQPad device, choose the stacking kit to mechanically attach both systems. Power Options SC-2345 and SC-2350 carriers have three power options: • SCC-PWR01 – 5 VDC from the DAQ device or an external supply • SCC-PWR02 – universal AC external supply • SCC-PWR03 – 7 to 42 VDC external supply module (power supply not included) One power module is included with your carrier. Power modules are sold separately in case you want to use your SC-2345 or SC-2350 in two or more configurations. If you choose the SCC-PWR01, it is possible to power your SCC system with the internal power source of your DAQ device. NI DAQCards and DAQPads provide 800 mW of total power (480 mW of analog power) from their internal source. NI PCI and PXI devices provide 4.50 W of total power (1.74 W of analog power) from their internal source. If the power draw from your SCC modules is greater than the power available from your DAQ device, then you must use an external power source. The SCC-PWR02 includes an AC transformer. However, you must purchase an additional power cord to match your country’s power requirements. The SCC-PWR03 does not include a transformer but can be used with an external transformer that provides 7 to 42 VDC. To determine the valid power options for the modules in your SCC DAQ system, use the online SCC Advisor at ni.com/advisors Momentary switch Toggle switch Rocker switch LED Potentiometer Strain relief Blank Table 1. SC-2345/SC-2350 Panelette Options Panelettes If you choose either of the two versions of the SC-2345 with configurable connectors or the SC-2350 as your carrier, then you can install connectivity and interface panelettes to customize your SCC system. Panelette options (see Table 1, Figure 4) include BNC, SMB, LEMO (B-Series), MIL-Spec, banana jack, thermocouple plug, 9-pin D-Sub connectors, rocker switches, toggle switches, momentary switches, potentiometers, and LEDs. Please note, some panelettes occupy more than one panelette slot. All panelettes except for the strain-relief options include lead wires that you connect to the screw terminals of any SCC module or to the 42-pin screw terminal block inside the SC-2345 or SC-2350. The thermocouple and minithermocouple jack connector wires are made of the appropriate metals to avoid forming unwanted cold junctions. Cabling You connect your SC-2345 or SC-2350 to your DAQ device using standard cables. To determine the cabling needed for your configuration, see Table 2. DAQ Device 68-pin E Series or Basic multifunction 100-pin E Series Latching E Series DAQCards: 6062E, 6036E, 6024E 1Can Screw Terminals Each SC-2345 and SC-2350 shielded carrier includes a 42-position screw terminal block for easy access to digital lines of the E Series or Basic Multifunction DAQ device, including DIO, PFI, GPCTR 0,1, +5V, DGND, AISENSE, FREQ_OUT, EXTSTROBE, and SCANCLK. SC-2345 SH68-68-EP1 SH1006862 SHC6868-EP also use the SH68-68R1 or R6868 2Only the first 68 pins will interface to an SC-2345 Table 2. SC-2345 Cabling Options Minithermocouple BNC SMB 9-Pin D-Sub Banana Jack LEMO (B-Series) MIL-Spec Toggle Switch Rocker Switch LED Strain Relief Potentiometer Momentary Switch Blank Figure 4. SC-2345/SC-2350 Panelette Photos National Instruments • Tel: (800) 433-3488 • Fax: (512) 683-9300 • info@ni.com • ni.com 3 Portable, Shielded SCC Module Carriers Ordering Information NI SC-2345 Connector Block with SCC-PWR01..............................................................777458-01 SCC-PWR02..............................................................777458-02 SCC-PWR03..............................................................777458-03 NI SC-2345 with Configurable Connectors (side 68-pin) with SCC-PWR01..............................................................777722-01 SCC-PWR02..............................................................777722-02 SCC-PWR03..............................................................777722-03 NI SC-2345 with Configurable Connectors (rear 68-pin) with SCC-PWR01..............................................................778018-01 SCC-PWR02..............................................................778018-02 SCC-PWR03..............................................................778018-03 SC-2350 with Configurable TEDS Connectors SCC-PWR01..............................................................778990-01 SCC-PWR02..............................................................778990-02 SCC-PWR03..............................................................778990-03 Separate Power Modules Panelettes (continued) SMB (4 included) ..........................................................185505-01 9-pin D-Sub 1 male ........................................................................184738-01 2 male ........................................................................184738-02 1 female......................................................................184738-03 2 female......................................................................184738-04 Strain relief (small) ......................................................184721-01 Blank ..............................................................................184483-01 Momentary push-button switches (2 included) ........185380-01 Rocker switch (on/off/on) ............................................185379-01 Toggle switches (on/off/on, 2 included) ......................185378-01 Potentiometer (10 kΩ, single-turn) ............................185377-01 LEDs (4 included-1 green, 1 red, 1 orange, 1 yellow) ....................................................185376-01 Cables SCC-PWR01 ..................................................................183971-01 SCC-PWR02 ..................................................................183971-02 SCC-PWR03 ..................................................................183971-03 Power Cords for the SCC-PWR-02 U.S. 120 VAC..................................................................763000-01 Japan 100 VAC ..............................................................763000-01 United Kingdom 240 VAC ............................................763064-01 Swiss 220 VAC ..............................................................763065-01 Australian 240................................................................763066-01 Universal Euro 240 VAC................................................763067-01 North American 240 VAC ............................................763068-01 Panelettes SH6868-EP 1 m ............................................................................184749-01 2 m ............................................................................184749-02 SH68-68R1-EP ..............................................................187051-01 R6868 ............................................................................182482-01 SH1006868 1 m ............................................................................182849-01 2 m ............................................................................182849-02 PSHR68-68 shielded cable kit ......................................777293-01 SHC6868-EP..................................................................186838-01 Accessories Minithermocouple, J-type (2 included) ......................184736-01 Minithermocouple, K-type (2 included) ....................184736-02 Minithermocouple, uncompensated (2 included) ......184736-03 Thermocouple, J-type ..................................................187597-01 Thermocouple, K-type..................................................187597-02 Thermocouple, uncompensated ..................................187597-03 BNC (2 included)..........................................................184737-01 Banana jack (2 included) ..............................................186405-01 LEMO (B-Series) 2-pin, female..............................................................187585-01 4-pin, female..............................................................187585-02 6-pin, female..............................................................187585-03 MIL–C–26482 (Series 1) MS 3112 E 8-2 S ......................................................187591-01 MS 3112 E 8-2 S ......................................................187591-02 MS 3112 E 8-4 S ......................................................187591-03 Rack-mount kit (1U) ....................................................777665-01 Stacking kit ....................................................................777666-01 Panel mount kit ............................................................187243-01 Strain relief kit1 ............................................................187407-01 1You cannot use the strain relief kit in conjunction with the rack-mount, panelmount, or stacking kits. BUY ONLINE! Visit ni.com/info and enter sc2345 or sc2350. Specifications SCC-PWR01 Input.................................................................. Output............................................................... 5 VDC ±5% from an external source, E Series, or Basic multifunction DAQ device +5 VDC, 100% efficiency ±15 VDC, 62% efficiency SC-2345 connector block ................................. SC-2345 with configurable connectors and SC-2350 ..................................................... External AC adapter (for SCC-PWR02) ............ 24.1 by 26.2 by 3.94 cm (9.5 by 10.3 by 1.6 in.) 30.6 by 25.4 by 4.4 cm (12.1 by 10 by 1.7 in.) 15.5 by 8.5 by 4.8 cm (6.1 by 3.3 by 1.9 in.) SCC-PWR02 Input.................................................................. Output .............................................................. 100 to 240 VAC, 1 A maximum +5 VDC, 1 A ±15 VDC, ±0.3 A Connectors SC-2345 cable .................................................. SCC input.......................................................... SCC output ...................................................... 68-pin male SCSI II Removable screw terminal or minithermocouple connector 20-pin right-angle male connector SCC-PWR03 Input ................................................................ Output............................................................... 7 to 42 VDC (from external source) +5 VDC, 75% efficiency ±15 VDC, 46% efficiency Physical Dimensions SCC modules .................................................... 8.9 by 2.9 by 1.9 cm (3.5 by 1.2 by 0.7 in.) 4 National Instruments • Tel: (800) 433-3488 • Fax: (512) 683-9300 • info@ni.com • ni.com NI Services and Support NI has the services and support to meet your needs around the globe and through the application life cycle – from planning and development through deployment and ongoing maintenance. We offer services and service levels to meet customer requirements in research, design, validation, and manufacturing. Visit ni.com/services. Local Sales and Technical Support In offices worldwide, our staff is local to the country, giving you access to engineers who speak your language. NI delivers industryleading technical support through online knowledge bases, our applications engineers, and access to 14,000 measurement and automation professionals within NI Developer Exchange forums. Find immediate answers to your questions at ni.com/support. We also offer service programs that provide automatic upgrades to your application development environment and higher levels of technical support. Visit ni.com/ssp. Training and Certification NI training is the fastest, most certain route to productivity with our products. NI training can shorten your learning curve, save development time, and reduce maintenance costs over the application life cycle. We schedule instructor-led courses in cities worldwide, or we can hold a course at your facility. We also offer a professional certification program that identifies individuals who have high levels of skill and knowledge on using NI products. Visit ni.com/training. Hardware Services NI Factory Installation Services NI Factory Installation Services (FIS) is the fastest and easiest way to use your PXI or PXI/SCXI™ combination systems right out of the box. Trained NI technicians install the software and hardware and configure the system to your specifications. NI extends the standard warranty by one year on hardware components (controllers, chassis, modules) purchased with FIS. To use FIS, simply configure your system online with ni.com/pxiadvisor. Professional Services Our Professional Services Team is comprised of NI applications engineers, NI Consulting Services, and a worldwide NI Alliance Partner Program of more than 600 independent consultants and integrators. Services range from start-up assistance to turnkey system integration. Visit ni.com/alliance. Calibration Services NI recognizes the need to maintain properly calibrated devices for high-accuracy measurements. We provide manual calibration procedures, services to recalibrate your products, and automated calibration software specifically designed for use by metrology laboratories. Visit ni.com/calibration. Repair and Extended Warranty OEM Support We offer design-in consulting and product integration assistance if you want to use our products for OEM applications. For information about special pricing and services for OEM customers, visit ni.com/oem. NI provides complete repair services for our products. Express repair and advance replacement services are also available. We offer extended warranties to help you meet project life-cycle requirements. Visit ni.com/services. ni.com • (800) 433-3488 National Instruments • Tel: (512) 683-0100 • Fax: (512) 683-9300 • info@ni.com © 2004 National Instruments Corporation. All rights reserved. Product and company names listed are trademarks or trade names of their respective companies.
